Truck Trailer Suspension Air Pillow W01-M58-8472 Firestone VOL-VO Air Ride Spring 20427800

Categories Truck Air Springs
Brand Name: GUOMAT
Model Number: 1T8472
Certification: ISO/TS16949:2009
Place of Origin: CHINA
MOQ: 6pcs
Price: $89.9-99.9/pc
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000pcs/week
Delivery Time: 3-8 work days
Packaging Details: strong carton box or as customers need
Product Name: Truck Air Springs
Color: Black
Packaging: Carton
Shape: Cylindrical
Material: Rubber and Steel
Contitech: 6605NP01
Goodyear: 1R11-805
Phoenix: 1DF20D-1
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Truck Trailer Suspension Air Pillow W01-M58-8472 Firestone VOL-VO Air Ride Spring 20427800

Truck/Trailer Suspension Air Pillow W01-M58-8472 Firestone VOL-VO Air Ride Spring 20427800


Product Description


The Firestone truck air spring with the part number W01-M58-8472 is a high-quality air spring used in trucks and trailers. It is compatible with various truck models and is designed to provide suspension support and shock absorption.


Cross Reference Number:

Firestone Part Number # W01-M58-8472

Firestone Part Number # W01M588472

Firestone Part Number # W01 M58 8472

Contitech Part Number # 6605NP01

Contitech Part Number # 6605 NP 01

Contitech Part Number # 6605 NP01

Goodyear Part Number # 1R11-805

Goodyear Part Number # 1R11 805

Goodyear Part Number # 1R 11-805

Phoenix Part Number # 1DF20D-1

Phoenix Part Number # 1 DF 20D-1

Dunlop FR Part Number # D11B42


ManufacturerPart NumberManufacturerPart Number
Airtech37803KAirfren20.6605.1CM
DT2.62176Templin04.060.6106.991
Granning93914WABCO9518110050
MeritorMLF7154VOL-VO20427800
VOL-VO20427803VOL-VO20456150
VOL-VO20531984VOL-VO20582206
VOL-VO3171692--

GUOMAT 1T8472 Detailed Technical Parameters
Top cover diameter: 231mm
Base diameter: 200mm
Combination column of top cover: M16X1.5/M24X1.5
Base bolt: M14X2.0
Natural outer diameter: 280mm
Maximum height: 502mm
Minimum height: 198mm
Piston height: 164mm


Installing Air Springs in VOL-VO Trucks

Prepare the vehicle: Before working on the vehicle, set the parking brakes, place the transmission in neutral, and block the wheels to prevent unexpected vehicle movement .

Remove the old air springs:

Remove the retaining clip from the bottom stud of the air spring .
Unscrew the air spring from the bottom of the cab .
Install the new air springs:

Install the spring plate on top of the new air spring .
Screw the new air spring into the bottom of the cab .
For the VN780 vehicle, place the bottom stud through the cab suspension crossmember and install a new retaining clip over the stud .
Apply pipe sealer to the fitting and install the air fitting in the bottom of the air spring .
Complete the installation:

Install the air line and start the truck to allow the air system to refill .
Remove the bottle jack and the cab supports .
Check for air leaks .
