| Categories | PVC Ball Valve |
|---|---|
| Model NO.: | QX |
| Structure: | Fixed Ball Valve |
| Type: | Fixed Ball Valve |
| Function: | Shutoff |
| Temperature: | Normal Temperature |
| Standard: | ANSI,DIN,BS,JIS,Cns |
| Application: | Industrial Usage, Water Industrial Usage, Household Usage |
| Color: | Light Gray, Deep Gray, Black, White |
| Standard Like: | DIN, BSPT, ASTM, ANSI |
| Quality: | EPDM Rubber+PVC Ball+PVC Handle, High Thickness |
| Package: | Plastic Bag Each One, Stron Export Carton |
| Feature: | New Fashion Handle, Easy Use, Long Service Life |
| Transport Package: | Carton, Polybag, Color Box or Customized |
| Specification: | 1/2′, 3/4′, 1′, 1-1/4′, 1-1/2′, 2′, 2-1/2′, 3", 4" |
| Trademark: | QX |
| Origin: | Zhejiang, China |
| HS Code: | 8481804090 |
| Supply Ability: | 70000 Piece /Month |
| Media: | Water |
| Material: | PVC |
| Connection Form: | Socket or Threaded |
| Driving Mode: | Manual |
| Nominal Pressure: | Pn10, Pn16 |
| Channel: | Straight Through Type |
| Samples: | US$ 3/Piece 1 Piece(Min.Order) | Request Sample |
| Customization: | Available | Customized Request |
| MOQ: | 1pc |
| Packaging Details: | Customized |
| Delivery Time: | 5-8 days |
| Payment Terms: | L/C,T/T |
| Company Info. |
| Ningbo Qianxiang Huiya International Trade Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
| NO. | PART | Material | QTY |
| 1 | Handle | PVC | 1 |
| 2 | O-Ring | EPDM | 2 |
| 3 | Stem | PVC | 1 |
| 4 | End Connector | PVC | 1 |
| 5 | Union Nut | PVC | 1 |
| 6 | Ball | PVC | 1 |
| 7 | Seat | TPE | 2 |
| 8 | O-Ring | EPDM | 1 |
| 9 | Body | PVC | 1 |
| SIZE | D | d | H | H1 | h | L | L1 | L2 |
| DN20 (3/4") | 58.8 | 18 | 79.5 | 45 | 87 | 18 | 64.5 | 39.3 |
| DN25 (1") | 67.5 | 23 | 91 | 51 | 101 | 22 | 75 | 44 |
| DN32( 1 1/4") | 79.3 | 31.4 | 105.5 | 57 | 115 | 24 | 85.5 | 51.5 |
| DN40(1 1/2") | 92.4 | 36 | 117.5 | 69.5 | 129 | 24 | 94 | 55 |
| DN50 (2") | 113 | 46.3 | 146 | 90 | 159 | 28 | 110 | 59.5 |
| DN65( 21/2") | 144.5 | 63.5 | 170 | 102 | 191 | 34 | 137.4 | 79.7 |
| DN80 (3") | 168 | 77 | 201.5 | 125.5 | 227.5 | 38 | 157.8 | 96.5 |
| DN100 (4") | 210 | 96 | 250 | 166 | 263.7 | 42 | 180 | 107 |
Our strength:
About product:
100% new materials.
Environmental friendly product with non-toxic.
Good looking and life long service.
Quality will be strongly controlled while producing, testing and
packing before leaving the factory.
Wonderful ability in chemical corrosion resistance.
Easy and fast installation, lowering the cost.
Customized.
About service:
We have full exporting experience to Southeast Asia, Africa, Middle
east, North America and South America.
Different quality and thickness valves with various style offered
to meet customer's need from region to region.
Free samples offered.
Each order will be carefully taken of even the order quantity is
small.
After-sale will be responded and solved in short time.
OEM is available.
Quick and stable delivery time.
|
