| Categories | Sinotruk Gas Generator |
|---|---|
| Model NO.: | T12 |
| Standard: | Standard |
| Transport Package: | Wooden Cases |
| Specification: | no |
| Trademark: | sinotruk fuqiang |
| Origin: | Chins |
| HS Code: | 84099990 |
| Supply Ability: | 50000 |
| After-sales Service: | Avaivable |
| Warranty: | 1500 Hours |
| Output Type: | DC |
| Gas Source: | Gas |
| Certification: | ISO9001 |
| Power: | 50-200kW |
| Customization: | Available | Customized Request |
| Place of Origin: | china |
| MOQ: | 1 |
| Price: | 10-1000 |
| Packaging Details: | Wooden box and carton packaging |
| Delivery Time: | 15 days |
| Payment Terms: | TT,western |
| Company Info. |
| Jinan Guohua Green Power Equipment Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
|
 | 50Hz,cosφ=0.8, 400/230V,3P,4W | Gas Engine |
 | Overall Size(mm) |
 | ||
|
 |
 | Model |
 | ||||
| T120GF-S | 120/150 | 132/165 | WT615D-1 | 138 | : | 2850*970*1700 | 2200 |
| T140GF-S | 140/175 | 154/192 | WT615D-3 | 161 | 2850*970*1701 | 2200 | |
| T150GF-S | 150/187 | 165/206 | WT615D-5 | 173 | 2850*970*1702 | 2200 | |
| T180GF-S | 160/200 | 176/220 | WT615D-7 | 185 | 2850*970*1703 | 2200 | |
| T140GF-S | 180/225 | 198/248 | T12-1 | 220 | 2880*1000*1800 | 2600 | |
| T200GF-S | 200/250 | 220/275 | T12-2 | 240 | 2880*1000*1801 | 2600 | |

Jinan Guohua Green Power Equipment Co.,Ltd(JNGH),is a high-tech sales &service company of Jinan Diesel Engine Co., Ltd. Established in 2010,JNGH has formed a complete system in sales and after-sales of 190 series engine(jichai brand:6L190,8V190,12V190.16V190)
Early stage:Consultation,designation, supply and erection of engine-based power plants,including diesel generator,natural gas
generator,coal gas generator and biogas generator.
Mid stage:Parts supply of jinan diesel engine(jichai/chidong
brand).JNGH has two warehouses.One located in Jinan which supply
the domestic north and south market.One located in Xinjiang
province which supply the west market.Thus could delivery parts
fast and guarantee the quality.
Later stage:JNGH also offer engine overhaul and maintenance
service.With experienced engineer and professional skills,the
problems could be easy solved.Not only the domestic
China,Ghana,Kazakhstan,Vietnam and Myanmar also could see the trace
of JNGH.
Later stage:Overhaul and maintenance service offered.
| Model of genset | Model of engine | Rated Power(KW/KVA) | Rated Voltage(V) | Rated Frequency(HZ) | Overall Dimension L*B*H(mm) | Net weigh(KG) | Fuel | |
| 700GF-TK2 | A12V190ZLT-2 | 700/875 | 400/230 | 50 | 5620*2180*2520 | 16000 | natural gas | |
| 800GF-W | AD12V190ZLW-2 | 800/1000 | 400/230 | 50 | 7040*2335*2520 | 20200 | coal mine gas | |
| 1000GF-NK | AD12V190ZLZ | 1000/1250 | 400/230 | 50 | 5375*2312*2776.5 | 16500 | biogas | |
| 1000GF-TK1 | AD12V190ZLT1 | 1000/1250 | 400/230 | 50 | 5375*2312*2776.5 | 16500 | natural gas | |
| 1000GF-TK2 | AD12V190ZLT2 | 1000/1250 | 400/230 | 50 | 5375*2312*2776.5 | 16500 | natural gas | |
| 1000GFZ-TK2 | AD12V190ZLT3 | 1000/1250 | 400/230 | 50 | 5375*2312*2776.5 | 16500 | natural gas | |
| 1000GF-T | AD12V190ZLT2 | 1000/1250 | 400/230 | 50 | 6660*2335*2520 | 19800 | natural gas | |
| 1000GF-T3 | AD12V190ZLT2 | 1000/1250 | 400/230 | 50 | 6660*2335*2520 | 19800 | natural gas | |
| 1000GF-T4 | AD12V190ZLT2 | 1000/1250 | 400/230 | 50 | 6660*2335*2520 | 19800 | natural gas | |
| 1100GF-WK | H16V190ZLW-2 | 1100/1375 | 400/230 | 50 | 5920*2180*2200 | 17200 | coal mine gas | |
| Main specification for gas engines | ||||||||
| Model | Rated Power(KW) | Rated Speed(r/min) | Compression ratio | Specific heat consumption(kj/kw.h) | Specific oil consumption(g/kw.h) | Overall Dimension L*B*H(mm) | Net weigh(KG) | FUEL |
| AD12V190ZLT1 | 1100 | 1500 | 12:01 | ≤11000 | ≤1.6 | 2979*2312*2471 | 9300 | natural gas |
| AD12V190ZLT2 | 1100 | 1500 | 10:01 | ≤9500 | ≤1.0 | 2979*2312*2471 | 9300 | natural gas |
| AD12V190ZLT3 | 1100 | 1500 | 10:01 | ≤9500 | ≤1.0 | 2979*2312*2471 | 9300 | natural gas |
| AD12V190ZLW-2 | 900 | 1000 | 10:01 | ≤9500 | ≤1.0 | 2979*2312*2471 | 9300 | coal mine gas |
| H12V190ZLT | 1500 | 1500 | 12:01 | ≤9500 | ≤1.0 | 3830*1792*2315 | 9300 | natural gas |
| H16V190ZLT-2 | 1200 | 1000 | 10:01 | ≤9500 | ≤1.0 | 3692*2516*2405 | 13000 | natural gas |
| H16V190ZLW-2 | 1200 | 1000 | 10:01 | ≤9500 | ≤1.0 | 3692*2516*2405 | 13000 | natural gas |
|   |
