| Product Name: | Pneumatic Air Knocker |
| Inlet Size: | 1/4'' |
| Exhaust Size: | 1/4'' |
| Body Material: | Aluminum Alloy |
| Working Pressure: | 3 to 7 bar |
| Air Consumption: | 0.228 L/Time |
| Impact Force: | 7.1 to 10.8 kgm/s |
| Net Weight: | 5.1kg |
| Company Info. |
| Ningbo Brando Hardware Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
SK-60 SEISHIN Type Pneumatic Air Knocker Percussion Hammer SK60
This is SK-60 air knocker similar to SEISHIN. Pneumatic air knocker keeps on hammering without a break to remove powder clogging and adhesion in hoppers and pipes, which are popularly used for many applications in fields such as manufacturing, food processing and pharmaceuticals.
Technical Data:
| Model No | Working Pressure (bar) | Air Consumption (L/Time) | Wallop (kgm/sec) |
| SK-30 | 3 to 7 | 0.028 | ~0.75 |
| SK-40 | 3 to 7 | 0.082 | ~2.2 |
| SK-60 | 3 to 7 | 0.228 | ~7.4 |
| SK-80 | 4 to 5 | 0.455 | ~16.4 |
| SK-100 | 5 to 7 | 1.012 | ~30.0 |
Main Dimension:
| Model No | A | B | C | D | E | G | H | L | S | T | Y | R |
| SK-30 | 75 | 10 | 82 | 13 | 9 | 1/8'' | 132 | 68 | 6 | 50 | 27 | 1/4'' |
| SK-40 | 90 | 12 | 97 | 18 | 11 | 1/4'' | 162 | 78 | 10 | 60 | 34 | 1/4'' |
| SK-60 | 121 | 13 | 143 | 19 | 15 | 1/4'' | 215 | 100 | 10 | 60 | 48 | 1/4'' |
| SK-80 | 160 | 17 | 170 | 20 | 17 | 3/8'' | 260 | 140 | 14 | 90 | 70 | 3/8'' |
| SK-100 | 200. | 18 | 200 | 23 | 17 | 3/8'' | 318 | 160 | 18 | 90 | 70 | 3/8'' |
Installation Examples:
