Brake & Wheel M3501 Air Spring Suspension Replace Goodyear 2B9-202 Air Bag H. 260MM

Categories Industrial Air Springs
Brand Name: AIRSUSTECH
Model Number: 2B6910
Certification: ISO/TS16949:2009
Place of Origin: Guangzhou,China
MOQ: 5
Price: Negotiable
Payment Terms: T/T, Western Union, Paypal or Others
Supply Ability: 1000PCS/Week
Delivery Time: 5-8 Working Days
Packaging Details: Strong Carton Box or as Customers Requirement
Structure: Double Convolutions
Brand: AIRSUSTECH
Product No.: 2B6910
Cross Reference: FD 200-19 320
Bellow MAX. Diameter: 251MM
Bolts Type: 3/8-16 UNC
MIN. H.: 75 MM
MAX. H.: 260 MM
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Brake & Wheel M3501 Air Spring Suspension Replace Goodyear 2B9-202 Air Bag H. 260MM

Brake & Wheel M3501 Air Spring Suspension Replace Goodyear 2B9-202 Air Bag H. 260MM

Product Description:

The AIRSUSTECH Air Springs are available in single, double and triple convolution types for virtually every conceivable heavy-duty vehicle suspension application. In addition, 2B6910 air spring is a carefully designed rubber/fabric bellows which contains a column of compressed air. The rubber bellows itself does not provide force or support load. This is done by the column of air.


Specifications and Detailed Technical Parameters


2B6910 Specifications

Air Hole
1/4 NPTF
Number of Ply BellowsDouble
Minimum Usable Height75 MM
Max Expanded Height260 MM
Stroke Height224 MM
Threaded Hole
2X3/8-16UNC
Top/Bottom Cover Plate Diameter185 MM
Hole/Stud QtyTwo On One Plate
Screw Center Distance89 MM
Distance Gas Hole Between Nut44.5 MM
Bellow Max. Diameter251 MM
Bellow Natural Diameter224 MM
Top/Bottom Plate Width160 MM

The Technical Dats Sheet Drawing of 2B6910:



Cross References:


Firestone

W01-358-6910, W01 358 6910

W013586910, WO1-358-6910

WO1 358 6910, WO13586910

Dayton

3546910

Contitech

FD 200-19 320, FD 200 19 320

FD20019320, FD 20019 320

FD 200 19320, FD 20019320

Leland

Sc2011

Goodyear

2B9-200/202/216
578423202

Navistar554783C1
Triangle6325/4320HendricksonS8768/458433
TaurusKF218-6910Ridewell1003586910C
Brake & WheelM3501SAF Holland57006910
DinaA812719/AZ812719Trailers De133128
Tuthill1371Watson & ChalinAS-0001/AS-0156G

We Have Other Models of The Same Rubber Bellows Number:


Guomat NO.Air InletThe MAX. Bellows OD.MIN. H.MAX. H.Nuts Type

Top/Bottom Cover

Plate Diameter

Screw Center DistanceDistance Gas Hole Betweeen Screw
2B6910P011/4 NPTF251 mm75 mm260 mm2×3/8-16UNC160 mm89 mm44.5 mm
2B6910-3/4G3/4251 mm75 mm260 mm2×M8×1.25160 mm89 mm38 mm
2B69101/4 NPTF251 mm75 mm260 mm2×3/8-16UNC160 mm89 mm44.5 mm
2B6910P021/4 BSP251 mm75 mm260 mm2×M8×1.25160 mm89 mm44.5 mm
2B6910P031/4 NPTF232.5 mm#240 mm2×3/8-16UNC160 mm89 mm44 mm
FAQ:
Q1: Is the sample available?
A: Yes, Usually we send the samples by TNT,DHL,FEDEX or UPS.
Q2:What is your warranty term?
A: There is a 12months warranty for our export products has run out from the date of the shipment.
Q3: What is your advantage?
A: (1) High quality - Natural rubber.
(2) Fast delivery - Stock sales.
(3) Best service - 24 hours online.

The Related Pictures of 2B6910:
