| Categories | Alumina Ceramic Crusher Parts |
|---|---|
| Brand Name: | HENGYUAN |
| Model Number: | Alumina Ceramic Crusher Parts |
| Certification: | CE,UL |
| Place of Origin: | WUXI JIANGSU CHINA |
| MOQ: | 100 |
| Price: | Negotiable |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 5000 PCS/WEEK |
| Delivery Time: | 20 DAYS |
| Packaging Details: | Carton |
| Material: | Alumina Ceramic Crusher Parts |
| Color: | Yellow Or White |
| Maximum Use Temperature: | 1600-1650℃ |
| Wear Resistance: | High Wear resistance |
| OEM,ODM: | Acceptable |
| Orgin: | WUXI JIANGSU CHINA |
| MOQ: | 100 |
| Package: | Carton |
| Company Info. |
| Yixing Hengyuan Ceramic Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Ceramic crusher, also known as composite ceramic crusher, is mainly used to crush ceramics, glass, stones, etc. The new product is optimized and designed based on the composite crusher combined with domestic and foreign fine crushing technology. Its performance has reached the advanced level in China and is used to crush various medium hard materials. It is widely used in industries such as mining, metallurgy, refractory materials, cement, coal, glass, ceramics, and power.
| Naterial | Unit | A95% Alumina Ceramics | A97% Alumina Ceramics | A99% Alumina Ceramics | A99.7% Alumina Ceramics |
| Density | g/cm³ | 3.6 | 3.72 | 3.85 | 3.85 |
| Flexural Strength | Mpa | 290 | 300 | 350 | 350 |
| Compressive Strength | Mpa | 3300 | 3400 | 3600 | 3600 |
| Modulus of Elasticity | Gpa | 340 | 350 | 380 | 380 |
| Impact Resistance | MPam1/2 | 3.9 | 4 | 5 | 5 |
| Weibull Modulus | M | 10 | 10 | 11 | 11 |
| Vickers Hardulus | HV0.5 | 1800 | 1850 | 1900 | 1900 |
| Thermal Expansion Coefficient | 10-6K-1 | 5.0-8.3 | 5.0-8.3 | 5.4-8.3 | 5.4-8.3 |
| Thermal Conductivity | W/Mk | 23 | 24 | 27 | 27 |
| Thermal Shock Resistance | △T℃ | 250 | 250 | 270 | 270 |
| *Maximum Use Temperature | ℃ | 1600 | 1600 | 1650 | 1650 |
| Volume Resistivity at 20℃ | Ω | ≥1014 | ≥1014 | ≥1014 | ≥1014 |
| Dielectric Strength | KV/mm | 20 | 20 | 25 | 25 |
| Dielectric constant | εr | 10 | 10 | 10 | 10 |


















|
