| Categories | Stainless Steel Strip |
|---|---|
| Brand Name: | TISCO |
| Model Number: | 301 / UNS S30100 / 1.4310 |
| Certification: | ISO |
| Place of Origin: | China |
| MOQ: | 2 Ton |
| Price: | 2380 - 3550 USD/Ton |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 20Ton per week |
| Delivery Time: | 5 - 12 days based on the quantity |
| Packaging Details: | standard packing for export |
| Products: | stainless steel strip |
| Thickness: | 0.1-2.5mm |
| Width: | within 1500mm |
| MOQ: | 500 kgs |
| Grade: | 200 series 300 series 300 series |
| Surface: | BA 2B NO.4 HL 8K NO.1 |
| Standard: | ASTM EN GB JIS |
| Packing: | wooden frame and water proof paper |
| Company Info. |
| JIANGSU MITTEL STEEL INDUSTRIAL LIMITED |
| Verified Supplier |
| View Contact Details |
| Product List |
301 Stainless Steel Strip ASTM/AISI/JIS/SUS/DIN Stainless Strip for Spring
| Product Name | Stainless Steel Strips |
| Length | As required |
| Width | 3mm-1219mm or as required |
| Thickness | 0.15 - 3.0mm or as required |
| Standard | AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc. |
| Technique | Hot rolled / cold rolled |
| Surface Treatment | 2B or according to customer requirement |
| Thickness tolerance | ±0.01mm |
| Material | 201, 202, 301, 302, 303, 304, 304L, 304H, 310S, 316, 316L, 317L, 321,310S 309S, 410, 410S,420, 430, 431, 440A,904L |
| Application | It is widely used in high temperature applications, medical devices, building materials, chemistry, food industry, agriculture, ship components.It also applies to food, beverage packaging, kitchen supplies, trains, aircraft, conveyor belts, vehicles, bolts, nuts, springs, and screen. |
| MOQ | 1tons.We also can accept sample order. |
| Shipment time | Within 15-20 workdays after receiving deposit or L/C |
| Export packing | Waterproof paper, and steel strip packed.Standard Export Seaworthy Package.Suit for all kinds of transport,or as required |
| Capacity | 250,000 tons/year |
High yield 301 stainless steel strip
301 Stainless Steel is an austenitic stainless steel capable of attaining very high strengths while maintaining ductility through cold working. Stainless Steel 301 can be used in mould goods. Also it can be quickly hardened by mechanical processing. It has good weldability. Its wear resistance and fatigue strength are better than that of 304 stainless steel. Compared with 304, its content of Cr and Ni is low. And it has magnetism after cold rolling.
301 is non-magnetic in the annealed condition and becomes increasingly magnetic with cold working. This chromium nickel stainless steel alloy provides high strength and good ductility when cold worked. 301 stainless steel is a modification of stainless steel grade 304 with lower chromium and nickel to increase the work hardening range. 301 steel exhibits corrosion resistance comparable to 304. In the cold worked and annealed condition,301 achieves its most optimal resistance to corrosion. It is preferable over 304 in the tempered condition because the higher enlongations (which are attainable at a given strength level) facilitate fabrication.
Chemical Composition(%)
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 301 | Min | – | – | – | – | – | 16.0 | 2.00 | 10.0 | – |
| max | 0.08 | 2 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | 0.1 |
Mechanical Properties
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 301 | 515 | 205 | 35% | 75 | 205 |
Classification
301 stainless steel strips can be classified as 301 soft steel strip, 301 medium hard steel strip(301 1/2 hard), 301 hard steel strip(301 full hard). It is determined by its chemical composition and processing technology.
Equivalent Grades of 301 Stainless Steel Strip
| STANDARD | UNS | JIS | WERKSTOFF NR. | AFNOR | BS | GOST | EN |
| SS 301 | S30100 | SUS 301 | 1.4310 | – | – | – | – |
|
