EBS Trailer Control Valve 4802040020 for Wabco Mercedes -Benz

EBS Trailer Control Valve 4802040020 for Wabco Mercedes -Benz

Technical specifications
Dimensions and weight: 176mm long, 169mm wide, 182mm high, and 2.978kg in weight.
Pressure parameters: Maximum working pressure can reach 123.28psi, and the delivery pressure is 123psi.
Electrical connection: Adopts bayonet DIN 72585 standard, rated current is 1400mA, and working voltage is 24V.
Port thread: Including M22 x 1.5, M16 x 1.5 and other different specifications.
Protection level: Reach IP 6k6k / IP 6k9k protection level, with good dustproof, waterproof and foreign object intrusion resistance.

Applicable models
Mainly suitable for tractors such as Mercedes-Benz Actros and their matching trailer vehicles, such as long-distance freight trucks, hazardous chemicals transportation vehicles, etc.

Features
Highly integrated with Wabco EBS system: As a key component of Wabco EBS system, it works perfectly with other components in the system, such as the electronic control unit (ECU), brake signal transmitter (BST), etc., to achieve precise control of trailer braking.
High reliability and durability: Made of high-quality materials and advanced manufacturing processes, it has undergone rigorous quality inspection and durability testing, and can work stably and long-term in harsh working environments.
Quick response: The application of electronic control technology enables it to respond extremely quickly, and can respond quickly the moment the driver steps on the brake pedal, effectively shortening the braking distance and improving the braking safety of the vehicle.
Precise pressure regulation: The air pressure of the trailer brake chamber can be accurately adjusted according to different braking requirements to ensure the braking synchronization and coordination between the trailer and the tractor, and reduce the impact and wear during braking.

EBS Trailer Control Valve 4802040020 is an electronic brake system trailer control valve developed by WABCO for Mercedes-Benz commercial vehicles. It has specific technical specifications, is compatible with relevant vehicle models, is highly integrated, reliable and durable, and requires good maintenance.
