SMP Female RF Coaxial Connector – Right Angle, Compatible with 2# Semi-Rigid / Semi-Flexible Cable

Categories RF Coaxial Connector
Brand Name: SIPU
Place of Origin: CHINA
MOQ: 50
Payment Terms: L/C, T/T, Western Union
Model Number: SMP-KWB2A
Certification: ISO9001-2017, RoHS, CE
Packaging Details: master carton
Price: Discuss
Delivery Time: 3-6 Weeks
Supply Ability: 100000pcs/year
Product name: SMP Female RF Coaxial Connector – Right Angle, Compatible with 2# Semi-Rigid / Semi-Flexible Cable
Dielectric withstanding voltage: 500V
Insulation resistance: ≥5000MΩ
Frequency range: DC-26.5GHz
Durability: 500 times
Gender: Female
Type: Right angle
Material: Beryllium bronze
Plating: Gold
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

SMP Female RF Coaxial Connector – Right Angle, Compatible with 2# Semi-Rigid / Semi-Flexible Cable

SMP Female RF Coaxial Connector – Right Angle, Compatible with 2# Semi-Rigid / Semi-Flexible Cable

Product Overview

The SMP series connector is an ultra-miniature RF coaxial connector featuring a plug-in, self-locking design. It is characterized by its compact size, light weight, high-frequency performance, quick-connect capability, and strong vibration resistance. The design allows for slight axial and radial misalignment, making it an excellent solution for modular, high-density installations.

Applications:
Broadband systems, antennas, test and measurement equipment, radar, and other high-frequency applications.

Product Features:

Right-angle structure

Compatible with 2# semi-rigid or semi-flexible cable

Compact and lightweight design

Strong shock and vibration resistance

Excellent electrical performance

Easy to solder and install

Product Specifications



Important Technical Parameters



Electrical property


Temperature range

-65~+125℃

Characteristic impedance


50Ω

Frequency range

DC-26.5GHz

Dielectric withstanding voltage


500V

VSWR

≤1.1+0.02F(GHz)

Insulation resistance


≥5000MΩ

Insertion loss

≤0.07√F(GHz)dB

Contact resistance

Center conductor

≤6.0mΩ

Mechanical property

Outer conductor

≤2.0mΩ

Durability

500times

Materials and Surface Treatment


Center conductor


Beryllium bronze, gold plating

Insulating medium

PTFE


Outer conductor


Beryllium bronze, gold plating

//
