P6 LED Advertising Screen Billboard For Bright Animation And 6000nits Brightness

Categories Outdoor Advertising LED Display
Place of Origin: Guangdong, China
Model Number: Gsurface
Brand Name: GCL
Packaging Details: Packing with Flight case & Wooden box & Hard paper box
Supply Ability: 5000 Square Meter/Square Meters per Month
Price: Negotiable
MOQ: Min. order: 20
Certification: EMC/CE/ROHS/CCC/FCC/BIS
Application: OUTDOOR
Type: LED
Color: FULL COLOR
Panel Size: 320*320mm
Usage: Outdoor Waterproof
Display Function: Animation
Brightness: 6000nits
Protection level: IP65
Viewing angle: 140/140 Degree
Refresh rate: 1920Hz-3840Hz
LED chip: Nationstar
Cabinet material: Iron
Control system: Novastar
Warranty: 3 Years
Pixel Pitch: P4 P5 P6 P8 P10
Port: Shenzhen
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

P6 LED Advertising Screen Billboard For Bright Animation And 6000nits Brightness

P6 P8 P10 Outdoor LED Display Billboard for Bright Animation and 6000nits Brightness

Easy Front Maintenance
Only need to loose two module locks to remove a module


No Steel Structure Needed
The cabinets can be installed on the wall directly without a steel structure.
Slimmer,easier.


Seamless L Shape Design


Great Gray Scale
Most LED screens from other suppliers have a low gray scale, so some of the colors can't be displayed on the screen, and the image on the LED screen appears like a ghost image. Our LED screen grays cale is 13bits ~ 16bits. It is very high so the image looks very vivid and perfect.

Stable Outdoor Fixed Installation
The LED display cabinet is made of steel material or aluminum material. We adopt the best materials and great crafts to manufacturing this LED display. Therefore, the LED screen functions are very stable in outdoor scenes.


Parameters of Gsurface Series:


NameP5.92P6.67P8P10P10BP16
Module
LED TypeSMD2727SMD2727SMD2727SMD2727DIP346DIP346
Pixel Pitch(mm)5.9256.6678101016
Module Resolution54*5448*4840*4032*3232*3220*20
Module Size(mm)320*320320*320320*320320*320320*320320*320
Scan Method1/6s1/6s1/4s1/2s1/4s静态
Cabinet
Module Quantity4*34*34*34*34*34*3
Cabinet Resolution216*162192*144160*120128*96128*9680*60
Cabinet Size(mm)1280*960*100;Customizable
Cabinet Area(㎡)1.2288
Cabinet MaterialProfile Aluminum
Cabinet Weight32kg32kg32kg32kg37kg35kg
Density(pixels/㎡)28476225001562510000100003096
Protection LevelIP65
Optics
Brightness(nits/㎡)65006500700070001000010000
CalibrationSupport Single-dot Calibration
Color Temperature1700-9500K Adjustable
Viewing AngleH140°,V140°
Light Decay Rate<3%
Contrast Ratio9000:01:00
Grey Scale13-16bit
Electric
Max Power Consumption/㎡640W700W680W680W360W420W
Average Power Consumption/㎡220W230W230W230W120W140W
Cabinet MaintenanceFull Front/Rear Service
Input VoltageAC100~240V(50-60Hz)
Performance
Drive ModeConstant Current Drive
Refresh Rate≥3840Hz
Frame Rate60Hz
Working Condition
Working Temperature/Working Humidity-20℃~+60℃/ 10%-90%RH
Storage Temperature/Storage Humidity-20℃~+60℃/ 10%-90%RH
CertificationsEMC/CE/ROHS/CCC/FCC/BIS
