| Categories | Outdoor Advertising LED Display |
|---|---|
| Place of Origin: | Guangdong, China |
| Model Number: | Grock |
| Brand Name: | GCL |
| Packaging Details: | To protect the LED screen well during the long transportation : 1) If it's for rental use, we will pack all cabinets by flight cases; 2) If it's for fixed installation, we will pack all cabinets by plywood cases. |
| Supply Ability: | 10000 Square Meter/Square Meters per Month |
| MOQ: | Min. order: 20 |
| Price: | Price to be discussed |
| Certification: | EMC/CE/ROHS/CCC/FCC/BIS |
| Application: | video play |
| Color: | full color |
| Panel Size: | customized |
| Pixel Pitch: | P4mm, 4mm |
| Cabinet size: | Customized |
| Module size: | 256*128mm |
| Warranty: | 3years |
| Brightness: | 5500nits |
| working encironment: | outdoor |
| Cabinet material: | Steel or Aluminum |
| Driving method: | 8S |
| Port: | SHENZHEN |
| Company Info. |
| Shenzhen GCL Electronics Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |


Product | P2.5 | P3 | P3.81 | P4 | |||
Pitch(mm) | 2.5 | 3 | 3.81 | 4 | |||
Density(pixels/m2) | 160000 | 111111 | 68798 | 62500 | |||
LED Type | SMD1415 | SMD1921 | SMD1921 | SMD1921 | |||
Brightness(nits) | 4000 | 5000 | 5500 | 5500 | |||
Scan Method | 1/16 | 1/16 | 1/8 | 1/8 | |||
Module size | 160mm*160mm | 192mm*192mm | 244mm*122mm | 256mm*128mm | |||
Cabinet Size(mm) | Customized | ||||||
Cabinet Material | Steel | ||||||
Cabinet Weight | 45kg/m2 | ||||||
Protection Level | IP65 | ||||||
Cabinet Maintenance | Rear Service | ||||||
Max Power Consumption | 600w/㎡ | 720w/㎡ | 800w/㎡ | 800w/㎡ | |||
Refresh Rate | 1920-3840HZ | ||||||
Grey Scale | 16 bit | ||||||
Viewing Angle | H160o,V140o | ||||||
Voltage | AC100~240V(50-63Hz) | ||||||
Working Temperature | -30 oC - + 65 oC | ||||||
Working Humidity | 10% -- 90%RH | ||||||
Color Temperature | 6500-9500K | ||||||
Certificationa | EMC/CE/ROHS/CCC/FCC/ISO | ||||||












|
