Deep Drawing Metal Sheet PE Stainless Steel Protective Film With High Elongation And Tear Resistance

Categories	Stainless Steel Protective Film
Place of Origin:	Jiangsu, China
Brand Name:	haoen
Model Number:	s-02
Packaging Details:	carton box for small rolls, air bubble film or corrugated paper for jumbo rolls，water-proof film wrapped on the pallet
Supply Ability:	20000 square meters/ day
MOQ:	10000 square meters
Price:	USD 0.1-0.3/ square meter
Certification:	Rohs, ISO9001, BSCI
Payment Terms:	L/C, T/T
Delivery Time:	5-10 working days
Material:	PE
Colors:	Blue
width:	30-2250mm
thickness:	50-80mic
length:	100-2000m
Elongation:	≥300%

Contact Now

Add to Cart

Company Info.

Wuxi Hao’en Protective Film Co., Ltd.

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

Deep Drawing Metal Sheet PE Stainless Steel Protective Film With High Elongation And Tear Resistance

Deep Drawing Metal Sheet PE Stainless Steel Protective Film With High Elongation And Tear Resistance

Product Description

Product Details

Perfect products need good protection! When profiles are turned into window frames, when stainless steel panels are processed into sinks, when painted metal sheets and plastics are transported and many more cases…Protective films prevent damage to surfaces, saving expensive reworking and unnecessary production losses…

Protective film can not only protect the surfaces of your valuable products during handling, mechanical, transporting,assembling and storage process ,but also can improve your brand image by printing your logo on its surface.

Features

High elongation and tear resistant; very good deformation behavior suitable for severe mechanical process and protect the stainless steel surface undamaged; easy unwind; can be easily applied and removed, leaving no residue glue after removal.

Main specification: 0.05mm-0.08mm;blue color

Production Process

Film -Blowing--->Printing--->Glue coating--->Testing--->Rewinding--->Cutting--->Shipping

Technical Data Sheet

Product model	HE-SD01
Application	stainless steel
Raw material	polyethylene
Glue type	water-based acrylic
Film blowing process	3 layer coextrusion
Recommended thickness	50mic, 60mic, 70mic, 80mic, 90mic, 100mic;
Recommended length	300m,500m,1000m;
Recommended width	1000 — 1300 mm
Colour	black & white, black & blue, blue;
Printing	up to 3 colour
Core diameter	76.2mm
Product performance	lazer cutting, Stamping forming, Scratch proof, puncture resistant, Dust proof and antifouling;
Recommended Peel Strength	50-200g/25mm
Recommended glue amount	4g, 6g, 8g
Tensile strength transverse	>20N
Tensile strength longitudinal	>20N
Elongation transverse	500%-600%
Elongation longitudinal	500%-600%
Optional performance	UV resistant for more than 12 months UV resistant for more than 6 months Anti convex roll (Patent No.ZL2022 2 0091200.2) Easy to tear wire design(Patent No.ZL2022 2 0078974.1)

Advantages

1. Film Type: Polyethylene film coated with pressure sensitive acrylic solvent adhesive or water-based adhesive
2. Color: Transparent; white; black and white; blue; black; green color and customized
3. Printability: can print logo, company name in 1-3 colors on the film surface
4. Recommended Thickness: 50-80 mic
5. Length: Within 2000 meters per roll
6. Width: Within in 1650 millimeter
7. Adhesive Strength: 5-1500g/50mm

Packaging

Stainless Steel Deep Drawing Metal Sheet PE Protective Film

Packing:Length: 100-1500 Meter Per Roll With Pallets

Storage

The product should be protected against direct sunlight and extremes in temperature and humidity and stored upright in its original packaging.

The film should be applied within a 12 month period from the delivery date. The film should be removed within 6 months from the date of lamination :

Surface preparation is important. The substrate should be clean and free from residue, such as dust and

oil, when the tape is applied in order to achieve optimum adhesion. Do not press too strong when applying. This may cause the end of the tape to peel. If applying to surfaces treated with machining oil, degrease the surface carefully. Any remains will be a

cause for surface contamination or adhesive residue.

Our Polyethylene film can protect numerous products to avoid scratch, mark, damage and dirt at the process of bending, pressing,roll forming, transportation and installation etc. The protective film can be easily applied and removed, leaving no residue glueon the surface of the protected products. Thus with the protection of the PE film, people can enhance the market competition of their valued products!

Our products have been exporting to Europe, Middle East, America, Japan etc. since 1999. With superior quality, competitive prices and perfect after-sales services, we can always guarantee your full satisfaction in working with us!

Company Profile

Our Services

FAQ

Q: Are you a manufacturer or trading company?

A:We are one of the leading manufacturer of protective filin China. We can supply one-stop service of customization for your special requirements.

Q : What are your main products?

A:Our main products are PE protective film.PE protective film can protect numerous products to avoid scratch, mark, damage and dirt during the process of bending, pressing, roll forming, transportation and installation etc.

Q: What is the MOQ for protective film?

A: 10,000 square meters.

Q: What is the lead time for protective film?

A: Within 20 days after receipt of your official order.
