Stainless Steel 304 Safety Fence Wire Suitable For Prisons

Categories Concertina Razor Wire
Brand Name: QiJie
Model Number: SGS2019025
Certification: Certification ISO2019025
Place of Origin: HeBei,China
MOQ: 1 rolls
Price: Discuss
Payment Terms: 30%TT
Supply Ability: 1500 Roll/Rolls per Week
Delivery Time: within 7-30 days
Packaging Details: Wooden carton
Material: galvanized steel sheet
application: Protecting Mesh, Fence Mesh
Finish: Hot Dipped Galvanized
Coil Outside Diameter: 960mm
extended length: 15m
name: galvanized razor barbed wire
Email: devin@industrialmetalmesh.com
whatsapp: +8615369013183
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Stainless Steel 304 Safety Fence Wire Suitable For Prisons

Stainless Steel 304 Safety Fence Wire Suitable for Prisons
Razor barbed wire is a kind of modern security fencing materials fabricated with razor-sharp steel blade and high-tensile wire.
It can be installed to achieve the result of frightening and stopping to the aggressive perimeter intruders,
with piecing and cutting razor blades mounted at the top of the wall, also the special designs making climbing and touching extremely difficult.
The wire and strip are galvanized or PVC coated to prevent corrosion.
razor wire
Material:
Galvanized wire and plate
Heavy Zinc coated wire and plate
Stainless steel wire and plate
Process: galvanized steel plate or stainless steel plate punched into certain forms then attached to the steel wire in sharp angle to form the blades.
Barbed Types: BTO-10 BTO-18 BTO-22 CBT-60 CBT-65
razor wire
Razor barbed wire specification
Blade TypeThicknessWire Dia.Barb LengthBarb WidthBarb Spacing
BTO-100.5MM+/-0.052.5MM+/-0.110MM+/-115MM+/-126MM+/-1
BTO-120.5MM+/-0.052.5MM+/-0.112MM+/-115MM+/-126MM+/-1
BTO-180.5MM+/-0.052.5MM+/-0.118MM+/-115MM+/-138MM+/-1
BTO-220.5MM+/-0.052.5MM+/-0.122MM+/-115MM+/-138MM+/-1
BTO-280.5MM+/-0.052.5MM28MM+/-115MM53MM+/-1
BTO-300.5MM+/-0.052.5MM30MM+/-121MM54MM+/-1
CBT-600.6MM+/-0.052.5MM+/-0.160MM+/-232MM+/-1102MM+/-1
CBT-650.6MM+/-0.052.5MM+/-0.165MM+/-221MM+/-1102MM+/-1
Barbed Tape Wire Specification
Outside DiameterNo. of LoopsStandard Length per CoilTypeNotes
450mm337-8MCBT-60.65Single coil
500mm5612-13MCBT-60.65Single coil
700mm5613-14MCBT-60.65Single coil
960mm5614-15MCBT-60.65Single coil
450mm568-9M (3 CLIPS)BTO-10.12.18.22.28.30Cross type
500mm569-10M (3 CLIPS)BTO-10.12.18.22.28.30Cross type
600mm5610-11M (3 CLIPS)BTO-10.12.18.22.28.30Cross type
600mm568-10M (5 CLIPS)BTO-10.12.18.22.28.30Cross type
700mm5610-12M (5 CLIPS)BTO-10.12.18.22.28.30Cross type
800mm5611-13M (5 CLIPS)BTO-10.12.18.22.28.30Cross type
900mm5612-14M (5 CLIPS)BTO-10.12.18.22.28.30Cross type
960mm5613-15M (5 CLIPS)BTO-10.12.18.22.28.30Cross type
980mm5614-16M (5 CLIPS)BTO-10.12.18.22.28.30Cross type
