S SFP GE LH40 SM1310 Huawei AR G3 Optical TransceiverS SFP GE LH40 SM1310

Categories SFP Optical Transceiver
Brand Name: HUAWEI
Model Number: S SFP GE LH40 SM1310
Certification: CE
Place of Origin: CHINA
Speed: 1 Gbit/s
Wavelenth: 1310NM
payment: TT/LC
Standard compliance: 1000base-LX/LH
Connector type: LC
Transmit power (dBm): -5.0 to 0
Extinction ratio (dB): -3.0
Overload power (dBm): 0°C to 70°C (32°F to 158°F)
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

S SFP GE LH40 SM1310 Huawei AR G3 Optical TransceiverS SFP GE LH40 SM1310

S-SFP-GE-LH40-SM1310 Overview

Huawei S-SFP-GE-LH40-SM1310 is Optical Transceiver. It’s a Single-mode Module.

Quick Specs

Table 1 shows the Quick Specs.

Product CodeS-SFP-GE-LH40-SM1310
Transceiver form factoreSFP
Transmission speed1 Gbit/s
Center wavelength (nm)1310
Standard compliance1000base-LX/LH
Connector typeLC
Applicable cable and maximum transmission distanceSingle-mode fiber: 40 km
Transmit power (dBm)-5.0 to 0
Maximum receiver sensitivity (dBm)-23
Overload power (dBm)-3.0
Extinction ratio (dB)9
Operating temperature0°C to 70°C (32°F to 158°F)
Net Dimension(D x W x H mm)110 x 70 x 37

The Supported Switches

Figure 1. S-SFP-GE-LH40-SM1310 can be installed in the switch’s SFP slot.


Table 2 shows the Huawei hot switches which support S-SFP-GE-LH40-SM1310.

ModelDescription
S5700-28P-LI-AC24 x Ethernet 10/100/1000 ports, 4 Gig SFP, AC 110/220V
S5700-28TP-LI-AC24 x Ethernet 10/100/1000ports,2 Gig SFP and 2 dual-purpose 10/100/1000 or SFP,AC 110/220V
S5700S-52P-LI-AC48 x Ethernet 10/100/1000 ports, 4 Gig SFP, AC 110/220V
S5700-28P-PWR-LI-AC24 x Ethernet 10/100/1000 PoE+ ports, 4 Gig SFP, AC 110/220V
S5700-10P-PWR-LI-AC8 x Ethernet 10/100/1000 PoE+ ports, 2 Gig SFP, AC 110/220V
S5720-36C-EI-AC

28 x Ethernet 10/100/1000 ports,4 of which are dual-purpose 10/100/1000 or SFP,4 10 Gig SFP+,

1 interface slot, with 150W AC

S5700-28C-EI-AC24 x Ethernet 10/100/1000 ports, with 1 interface slot, with 150W AC power supply
S5720-56C-HI-AC48 x Ethernet 10/100/1000 ports, 4 10 Gig SFP+, with 2 interface slots, with 600W AC power supply
S5720-56PC-EI-AC48 x Ethernet 10/100/1000 ports,4 Gig SFP, with 1 interface slot, with 150W AC power supply
S5720-56C-PWR-HI-AC48 x Ethernet 10/100/1000 POE+ ports,4 10 Gig SFP+, with 2 interface slots, with 1150W AC power supply

Compare to Similar Items

Table 3 shows the comparison of S-SFP-GE-LH40-SM1310 and S-SFP-GE-LH40-SM1550.

ItemS-SFP-GE-LH40-SM1310 S-SFP-GE-LH40-SM1550
Transceiver form factoreSFPeSFP
Transmission speed1 Gbit/s1 Gbit/s
Center wavelength (nm)13101550
Standard compliance1000base-LX/LH1000base-LX/LH
Connector typeLCLC

Applicable cable and maximum

transmission distance

Single-mode fiber: 40 kmSingle-mode fiber: 40 km
Transmit power (dBm)-5.0 to 0-5.0 to 0
Maximum receiver sensitivity (dBm)-23-22
Overload power (dBm)-3.0-3.0
Extinction ratio (dB)98.5
Operating temperature0°C to 70°C (32°F to 158°F)0°C to 70°C (32°F to 158°F)
Net Dimension(D x W x H mm)110 x 70 x 37110 x 70 x 37
