| Categories | Cold Room |
|---|---|
| Model NO.: | R10X6X3 |
| Size: | Medium |
| Structure: | Assembled |
| Use Nature: | Distribution |
| Suitable for: | Factory |
| Usage: | Food, Blood, Medicine |
| Warranty: | 3-5 Years |
| Certification: | ISO, CCC |
| Condition: | New |
| Cooling Method: | Direct Cooling |
| Transport Package: | Standard Export Package |
| Specification: | 500tons |
| Trademark: | Hugcool |
| Origin: | China |
| Supply Ability: | 100 PCS/Month |
| Package Size: | 5000.00cm * 5000.00cm * 6000.00cm |
| Package Gross Weight: | 800.000kg |
| After-sales Service: | All Life |
| Temperature: | -10-0℃ |
| Refrigerant: | Freon |
| Customization: | Available | Customized Request |
| Shipping Cost : | about shipping cost and estimated delivery time. |
| : | Initial Payment Full Payment |
| Currency: | US$ |
| Return&refunds: | You can apply for a refund up to 30 days after receipt of the products. |
| Company Info. |
| Hugecool (Qingdao) Refrigeration Techonolgy Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Find us for Turn-Key cold storage project, design, manufacture, supply, installation,
commissioning, training, service
Panel Dimension
Polyurethane sandwiched panels are of 100% Polyurethane insulation,
which is constructed by being foamed in place with retarted
polyurethane using high pressure. They have certain dimensions.
Standard widths of panels are a multiple of 295.3mm. The maximum
lengths of panels are 12M. Non-standard sizes are also available
upon request with price varying.
Functions: Fresh-keep, freezing, quick-freezing, fire-proof,
explosion-proof, air-conditioning are all available
Tempreture:
| cold storage goods | tempreture range |
| processing room | 10C |
| fruit, vegetable, dry food | 0C~-5C |
| medicine, cake, pastry, chemical material | 0C~-5C |
| ice storage room | -5~-10C |
| fish, meat storage | -18~-25C |
| deep freezer | -25C~-60C |
Choice of the surface finished
A. Stucco Embossed Aluminium
B. Stainless Steel
C. Painted Galvanized Mild Steel
D. PVC Stell
E. Standard floor panels: 1.0mm galvanized mild steel
Panel thickness and Operating Temperature;
Cold storage temperature: -5C to +10C, panel thickness: 50mm, 75mm,
100mm;
Freezer storage temperature: -25 to +18C, panel thickness: 150mm,
180mm, 200mm;
Quick frozing temperature: -40C to +18C, panel thickness: 150mm,
180mm, 200mm.
Installation of panels:
Every panels consists of tongue and groove construction and can be
tightened by a number of exocentric fasteners, which may be
unscrewed easily with a hexagonal key.
|
