152 MM Firestone W01-M58-6140 Suspension Air Spring 114 MM Steel Cover Plate

Categories Firestone Air Bags
Brand Name: AIRSUSTECH
Model Number: 1B130070M8
Place of Origin: Guangzhou,China
Certification: ISO/TS16949:2009
MOQ: 2
Price: USD69.9/PC-USD199.9/PC
Packaging Details: Strong Carton Box or as Customers Requirement
Delivery Time: 5-8 Working Days
Payment Terms: T/T, Western Union, Paypal or Others
Supply Ability: 1000PCS/Week
MAX O.D. AT 7 BAR: 152 MM
Product Name: AIRSUSTECH Air Bags
Blind Nut Centers: 44 MM
Number of Bolts: 2 Pieces Per Plate
MIN H.: 48 MM
Force to collapse to minimum height (@ 0 BAR): 133 N.
Bead Rings: 114 MM
Material: Rubber+Steel
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

152 MM Firestone W01-M58-6140 Suspension Air Spring 114 MM Steel Cover Plate

152 mm Firestone W01-M58-6140 Suspension Air Spring 114.2 mm Steel Cover Plate

Product Description:


The AIRSUSTECH actuators are playing a crucial role in modern machine design as pneumatic actuators in industrial applications. Due to their durability, ability to withstand abrasive environments, and exceptional performance, AIRSUSTECH actuators are becoming a popular replacement for traditional pneumatic and hydraulic cylinders.


Cross References:


ContitechFS 50-5 CI61388
FS 50-5 61388
FS50-5 CI G1/4M8
FS 50-5 G1/4 M8
FS 50-5 CI/FS50-5CI/FS50-5CI
Contitech BellowFS 50-5/FS50-5/FS505
FirestoneW01-M58-6140/W01 M58 6140/W01M586140
Firestone Style16
Goodyear1B5-801/1B5 801/1B5801
1B5-810/1B5 810/1B5810
Goodyear Flex No.579-913-500/579 913 500/ 579913500

Features:

  • Product Name: AIRSUSTECH Air Springs
  • Material: Rubber+Steel
  • Design Height: 69 mm
  • MAX H.: 89 mm
  • MAX O.D. AT 7 BAR: 152 mm
  • Blind nuts, 1/4 BSP: W01-M58-6140
  • Assembly Weight: 1.13 kg
  • Bottom cover diameter: 114 mm
  • Blind Nut Centers: 44 mm
  • Compatible with Lifted Truck Air Bag Kits

Technical Parameters:


Bead plate Type1
Dim. A (Blind Nut Centers)45 mm
Maximum Diameter @ 7 Bar152 mm
Maximum Stroke41 mm
Force in kN @ 5 Bar at Stroke of 25 mm3.6
Force in kN @ 5 Bar at Stroke of Maximum Stroke2.5
Design Height76 mm
Load (at Design Height) at 3 Bar (kN)2
Load (at Design Height) at 5 Bar (kN)3.4
Load (at Design Height) at 7 Bar (kN)5
Natural Frequency (@5 Bar)(fn(Hz)3.9

Applications:


  • If you need to replace your existing air springs, the AIRSUSTECH Air Springs are an excellent choice. These air bags are designed to be easy to install and can be used as a direct replacement for many existing air springs.
  • The AIRSUSTECH 1B130070M8 is an ideal solution for a wide range of applications. Whether you're looking for a reliable air bag for your vehicle, trailer, or heavy machinery, these air bags are up to the task.
  • If you work in an industrial setting, the W01-M58-6140 is an excellent choice. These air bags are designed to provide reliable support and stability in even the most demanding industrial applications.

Support and Services:


The AIRSUSTECH Air Spring product offers a variety of technical support and services to ensure optimal performance and usage. These include:

  • Installation assistance
  • Product manuals and instructions
  • Warranty information and registration
  • Troubleshooting and diagnostic support
  • Replacement parts and accessories
  • Online resources and FAQ section
  • Expert advice and consultation

Our team of knowledgeable technicians and customer service representatives are available to assist with any questions or concerns regarding the AIRSUSTECH Air Bags product.
