40ft 50T TERMINAL SUPER HEAVY MACHINE TRANSIT MAFI FLATBED ROLLER TRAILER Semi-Trailer for Transport

Details Images

Product Paramenters

Mafi Trailer

Mafi Trailer also Called Roller Trailers belongs to the Terminal Logistic Equipment, but it is used for the bulk-Cargo TERMINAL and Roll-Roll Vessel Terminal . In the Bulk-Cargo Terminal, it is for the heavy Machine but without Suspending Point , then put the machine to the Mafi Trailer , and suspend it to the vessel. In The Roll-Roll Vessel, it is for the heavy machine without running systems or its running system can not fit for the Roll-Roll Loading, then use it as an rolling machine to load the cargos to the Vessel. It is also a way for the container load to bulk-Cargo Vessel or Roll-Roll Vessel. Mafi Trailer with the Steel Reinforced Rubber Tire for the capacity of 60T to 100T .

40 FEET 50T MAFI FLATBED ROLLER
1. MODEL:				GET9404MAFI
Mafi Trailer also Called Roller Trailers belongs to the Terminal Logistic Equipment, but it is used for the bulk-Cargo TERMINAL and Roll-Roll Vessel Terminal . In the Bulk-Cargo Terminal, it is for the heavy Machine but without Suspending Point , then put the machine to the Mafi Trailer , and suspend it to the vessel. In The Roll-Roll Vessel, it is for the heavy machine without running systems or its running system can not fit for the Roll-Roll Loading, then use it as an rolling machine to load the cargos to the Vessel. It is also a way for the container load to bulk-Cargo Vessel or Roll-Roll Vessel, it meets all D.O.T., A.A.R., ANSI, T.O.F.C., FMVSS, SAE and TTMA specifications.
2. GENERAL
Overall Length	41 ft	12,461 mm
Overall Width	9 ft	2,600 mm
Overall Height	2 ft	741 mm
Platform Height	29.61 in	752 mm	the chassis unload
ground clearance	9.45 in	240 mm	unladen
Tare Weight	25,360 Ibm	11,500. kg
Payload	110,240 Ibm	50,000. kg
3. STEEL STRUCTURE AND COMPONENTS
Frame	Auto-welt Main Beam With High strength low alloy steel with 350 MPa yield hot-rolled I-beam, ASTM A572 Grade 50 or equivalent (Q345)
Running Gear	2 rock arms lowered box construction 4 axles 140x140,φ100/80mm Taper roller bearings 30216 – 8 pieces, 32020 – 8 pieces
Deck	4mm thickness checkered steel floor plate.
Twist Locks	8 sets for 20ft and 40ft container
Tires	8 steel reinforced solid rubber tires 22”x16”x16”
Painting	Abrasive blast of all metal surfaces – not less than SA-2.5 to achieve clean bare steel Surface will be coated with marine paint of minimum 70% Zinc- Rich primer and true acrylic aliphatic urethane topcoat, color optional, total thickness not less than 80μm after dry membrane
MAX.SPEED	25 KM/H
Working .Speed	6km /h when full load

Manufacturing Technique

CUSTOMIZED DESIGN

Based on full understanding and analysis about transportation environment of various regions, refer to the millions of trailers’
producing experience and customer’s private condition, we design all the trailers privately to different customers..

TBEST STEEL CONSTRUCTION

Material choose the High strength low alloy steel with 350 mpa yield strength is used for welded I-beam and 235 mpa in other
fabricated parts and the original ALCOA aluminum for the tanks and dry logistic box.

AXLE SYSTEM

High quality axle from world brand of BPW, SAF TO China Famous brand FUWA, L1 with strong bearing capacity from 9T to 20T and ABS options to fit full demand of requirements.

SUSPENSION SYSTEM

High quality suspension from world brand of BPW, SAF TO China Famous brand FUWA, L1, from Leaf-spring plate type, bogie type to Air-Spring type and rubber type to fit different requirements of the cargo delivery condition

TIRES AND RIMS

High quality tires from world brand of MICHELIN, BRIDGESTONE, PIRELLI to China Brand DOUBLE COIN, TRI-ANGLE, Coupled with RIMS
from STEEL to ALUMINUM.

SAFETY CONTROL SYSTEM

World brand brake system WABCO Valves with ABS or EBS to keep the trailers under control at any cases.

Company Profile

Manufacturing Products Ranges:

1. Terminal Logistics Truck Trailers:
From Mafi Trailer, Container Chassis and Skeleton Semi-trailers to Flatbed, Drop Side Semi-Trailer to delivery containers full loaded worldwide cargos to create an international value for a better urban life.

2. Energy Logistics Tankers
From Steel and Aluminum Tanker Trucks Transport the fossil fuel and The Stainless Steel Tankers for Fresh Juice and milk to support your daily City life to The Green energies Pressure Vessel for LPG, CNG, LNG and their Storage Tankers for Bottling Station to protect the environment, and create environmental values for a better Earth Future.

3. Cold Chain Logistics Trucks
From Lab Used Ultralow Temperature Cold Room and Prefabricated Modular Walk-in Cold Room to the huge Cold Storage and food processing factory to the Insulated and Refrigerated Composite Trucks with Thermoking and Carrier freezing Units for the Fresh Vegetable and frozen food, Storage and Transportation to supply a Health and Rich Tables for our better Urban Life.

4. Cargo Logistics Vehicles
From Drop-Side Trailers, Curtain-Side Trailers deliver the bulk cargos and Low Bed Semi-Trailer for the construction or heavy industry machines to The Tipper Truck and Dump Trailers deliver the Construction materials for our city infrastructure construction to build a warm living home.

5. Customized Vehicles
With our highest Technology Teams 200 Engineers ‘s full time support, we have the super power to proposal the customized Special Vehicles to solve your special Demands, Like We did Sugar Cane Trailers for Kenya and Ethiopia; Cotton Loader semi-trailer with wing covers, and the Logging Draw Bar Trailers for small Logs and Logging Trailer For Huge Logs and Car Carrier Trucks.Manufacturing Products Ranges:

Production Workshop

Packaging Delivery

Honorary Certificate

Customer Visiting

Container Truck Trailers

From Mafi Trailer, Container Chassis and Skeleton Semi-trailers to Flatbed, Drop Side Semi-Trailer to delivery containers full loaded worldwide cargos to create an international value for a better urban life.Terminal Logistics Truck Trailers:

Product Tags:


*From:	Your email address is incorrect!
*To:	GET INDUSTRY & VEHICLES CO.,LTD
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Categories	Container Chassis Trailer
Use:	Truck Trailer
Type:	Semi-Trailer
Material:	Steel
Size:	40 ft
Max Payload:	50T-100T
Place of Origin:	China
Brand Name:	GET
Certification:	DOT
Tire:	Rigid Tire
Axle:	100T Wheel-Tire Block
Twist Lock:	4/8/12 sets
Loading capacity:	30T ~ 100T
Usage:	Super heavy Cargos /Machines
Packaging Details:	BULK SHIPMENT
Port:	QINGDAO,CHINA
Supply Ability:	20 Unit/Units per Month
MOQ:	3 units
Price:	$25,000.00/units 3-5 units
