1. Product Introduction of 304 stainless steel plate
Our 304 hot rolled stainless steel sheets are crafted through a
high - temperature rolling process, resulting in robust and durable
products. With excellent mechanical properties and corrosion
resistance, these sheets are highly favored across multiple
industries.
2. Parameters of 304 stainless steel plate
- Composition: Composed of around 18% chromium and 8% nickel, 304 hot rolled
stainless steel sheets inherit the outstanding anti - corrosion
ability and high - temperature tolerance characteristic of 304
stainless steel. The addition of other trace elements further
optimizes its overall performance.
- Hardness: Typically exhibits a Brinell hardness (HB) range of 130 - 180,
ensuring a good balance between formability and strength.
- Tensile Strength: Boasts a tensile strength of ≥520 MPa, capable of withstanding
significant mechanical loads without deformation or breakage.
- Yield Strength: The yield strength is ≥205 MPa, providing reliable structural
stability in various applications.
3. Sizes of 304 stainless steel plate
- Thickness: Available in thicknesses ranging from 3mm to 60mm, catering to
different project requirements.
- Width: Offered in widths of 1250mm, 1500mm, 1800mm, and 2000mm.
- Length: Standard lengths include 6000mm, 8000mm, and 12000mm. Custom
lengths can also be provided according to customer needs.
4. Standards of 304 stainless steel plate
Our 304 hot rolled stainless steel sheets comply with multiple
international and domestic standards, such as ASTM A240/A240M in
the United States, which specifies requirements for chromium and
chromium - nickel stainless steel plates, sheets, and strips for
pressure vessels and general applications; JIS G4304 in Japan,
covering hot - rolled stainless steel plates, sheets, and strips;
and GB/T 4237 in China, setting the standards for hot - rolled
stainless and heat - resisting steel plates, sheets, and strips.
These standards ensure the quality, performance, and consistency of
our products.
5. Packaging of 304 stainless steel plate
- Inner Packaging: Each sheet is individually wrapped with moisture - proof paper to
protect the surface from scratches and oxidation during storage and
transportation.
- Outer Packaging: Multiple sheets are bundled together with steel straps, and then
covered with a waterproof plastic film to prevent damage from
moisture and external impacts. For large - scale orders, the
bundles are placed on wooden pallets for easy handling and
stacking.
6. Cutting Services of 304 stainless steel plate
We provide professional and precise cutting services to meet
diverse customer needs:
- Straight Cutting: Using advanced cutting equipment, we can cut the sheets into the
required lengths with high precision, minimizing material waste.
- Shape Cutting: Equipped with CNC cutting machines, we are able to cut the sheets
into various complex shapes according to customer - provided
drawings or specifications, ensuring accurate dimensions and smooth
edges.
7. Applications of 304 stainless steel plate
- Construction Industry: Widely used in building structures, such as large - scale
industrial plants, commercial buildings, and bridges, due to its
high strength and good corrosion resistance, which can extend the
service life of structures.
- Mechanical Manufacturing: Ideal for manufacturing mechanical parts, such as machine frames,
brackets, and components that require high strength and wear -
resistance.
- Chemical Equipment: Applicable in the construction of chemical reactors, storage
tanks, and pipelines, as it can resist the corrosion of many
chemical substances, ensuring the safe operation of chemical
equipment.
- Automotive Industry: Used in automotive manufacturing for parts like truck frames,
trailer bodies, and some internal structural components, taking
advantage of its excellent mechanical properties and durability.
