ASTM A240 316L Stainless Steel Shimming Strip 0.5mm - 3.0mm Thicknesses Widths

Categories	Stainless Steel Strip
Brand Name:	TISCO
Model Number:	316L / 1.4404
Certification:	ISO
Place of Origin:	China
MOQ:	2 Ton
Price:	2500 - 3450 USD/Ton
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	20Ton per week
Delivery Time:	5 - 12 days based on the quantity
Packaging Details:	standard packing for export
Products:	stainless steel strip
Thickness:	0.5-3.0mm
Width:	within 1500mm
MOQ:	500 kgs
Grade:	200 series 300 series 300 series
Surface:	BA 2B NO.4 HL 8K NO.1
Standard:	ASTM EN GB JIS
Packing:	wooden frame and water proof paper

Contact Now

Add to Cart

Company Info.

JIANGSU MITTEL STEEL INDUSTRIAL LIMITED

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

ASTM A240 316L Stainless Steel Shimming Strip 0.5mm - 3.0mm Thicknesses Widths

ASTM A240 316L Stainless Steel Shimming Strip 0.5mm - 3.0mm Thicknesses Widths

Products Specification

Product Name	316L Stainless Steel Strips
Length	As required
Width	3mm-1219mm or as required
Thickness	0.15 - 3.0mm or as required
Standard	AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc.
Technique	Hot rolled / cold rolled
Surface Treatment	2B or according to customer requirement
Thickness tolerance	±0.01mm
Material	201, 202, 301, 302, 303, 304, 304L, 304H, 310S, 316, 316L, 317L, 321,310S 309S, 410, 410S,420, 430, 431, 440A,904L,2205,2507
Application	It is widely used in high temperature applications, medical devices, building materials, chemistry, food industry, agriculture, ship components.It also applies to food, beverage packaging, kitchen supplies, trains, aircraft, conveyor belts, vehicles, bolts, nuts, springs, and screen.
Application
MOQ	1tons.We also can accept sample order.
Shipment time	Within 15-20 workdays after receiving deposit or L/C
Export packing	Waterproof paper, and steel strip packed.Standard Export Seaworthy Package.Suit for all kinds of transport,or as required
Export packing
Capacity	250,000 tons/year

Product Overview

Our 316L stainless steel strip is a premium-grade corrosion-resistant alloy product, meticulously manufactured to meet the highest industry standards. As a low-carbon variant of 316 stainless steel, it significantly reduces the risk of carbide precipitation during welding, ensuring superior intergranular corrosion resistance. This makes it an ideal choice for a wide range of applications, especially in highly corrosive environments.

Key Features

Exceptional Corrosion Resistance: Thanks to the addition of molybdenum, 316L stainless steel strip offers outstanding resistance to various chemicals, acids, and chloride solutions. It performs well in marine, pharmaceutical, and chemical processing environments, where exposure to harsh substances is common.

High-Temperature Stability: It can maintain excellent mechanical properties and structural integrity in high-temperature conditions, with a service temperature range typically from -196°C to 800°C. This feature makes it suitable for applications in heat exchangers, furnace parts, and exhaust systems.

Superior Formability: The strip has excellent cold-workability and ductility, allowing it to be easily formed into various shapes through processes like rolling, stamping, and bending. This enables the creation of customized components according to specific design requirements.

Low Magnetic Permeability: With its low magnetic properties, 316L stainless steel strip is an appropriate option for applications where magnetic interference needs to be minimized, such as in medical devices and precision instruments.

Hygienic and Easy to Clean: Its smooth surface resists dirt, bacteria, and other contaminants, making it a preferred material for the food and beverage, and medical industries where strict hygiene standards are required.

Technical Specifications

Parameter	Details
Chemical Composition	Carbon (C) ≤0.03%, Chromium (Cr) 16.0 - 18.0%, Nickel (Ni) 10.0 - 14.0%, Molybdenum (Mo) 2.0 - 3.0%, Manganese (Mn) ≤2.0%, Silicon (Si) ≤1.0%, Phosphorus (P) ≤0.045%, Sulfur (S) ≤0.03%
Thickness Range	0.05mm - 3.0mm
Width Range	5mm - 600mm
Length	Customizable
Standard	Complies with ASTM A240, EN 10088, JIS G4305, etc.
Surface Finish	2B (bright cold-rolled), BA (bright annealed), No.4 (polished), HL (hairline), mirror finish

Applications

Marine Industry: Used for shipbuilding components, seawater handling equipment, and offshore structures due to its excellent corrosion resistance in saltwater environments.

Medical Field: Applied in the production of surgical instruments, medical implants, and hospital equipment, leveraging its biocompatibility, hygiene, and low magnetic properties.

Food and Beverage: Ideal for food processing machinery, storage tanks, and kitchen equipment, ensuring compliance with strict hygiene regulations.

Chemical Processing: Suited for pipes, valves, and reactors in chemical plants, capable of withstanding highly corrosive chemicals.

Architectural Decoration: Used for decorative trims, handrails, and facade cladding, combining aesthetic appeal with durability and corrosion resistance.

Customization and Services

We offer comprehensive customization services to meet your specific needs. Our experienced technical team can assist with material selection, processing techniques, and surface finish options. Whether you require a specific size, shape, or surface treatment, we are committed to providing high-quality 316L stainless steel strips that exceed your expectations. Additionally, we ensure prompt delivery and reliable after-sales support to guarantee a seamless purchasing experience.
