| Categories | Used Concrete Pump Truck |
|---|---|
| Brand Name: | SANY |
| Place of Origin: | China |
| MOQ: | 1 |
| Price: | USD30000 - USD120000 EXW |
| Payment Terms: | L/C,T/T |
| Delivery Time: | in one week |
| Packaging Details: | Bulk Cargo Shipping |
| Chassis Brand: | SANY |
| Overall Length: | 11,705 mm |
| Emission Standard: | China V |
| Maximum Speed: | 85 km/h |
| Engine Displacement: | 8.7 L |
| Fuel Tank Capacity: | 400 L |
| Company Info. |
| Hunan Teila Heavy Industry Machinery Group Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Category | Parameter | Specification |
Vehicle Dimensions | Overall Length | 11,705 mm |
Overall Width | 2,550 mm | |
Overall Height | 3,970 mm | |
Total Weight | 30,000 kg | |
Boom Parameters | Vertical Height | 42.5 m |
Horizontal Length | 37.7 m | |
Vertical Depth | 30.2 m | |
Minimum Deployment Height | 11 m | |
Section 1 Length & Rotation Angle | 8,112 mm, 89° | |
Section 2 Length & Rotation Angle | 6,300 mm, 180° | |
Section 3 Length & Rotation Angle | 6,924 mm, 180° | |
Section 4 Length & Rotation Angle | 8,542 mm, 230° | |
Section 5 Length & Rotation Angle | 8,636 mm, 210° | |
Turret Rotation Angle | ±360° | |
Pumping System | Theoretical Concrete Output (Low Press.) | 120 m³/h |
Theoretical Concrete Output (High Press.) | 70 m³/h | |
Theoretical Pumping Pressure (Low Press.) | 8 MPa | |
Theoretical Pumping Pressure (High Press.) | 13 MPa | |
Delivery Cylinder Inner Diameter | 230 mm | |
Delivery Cylinder Stroke | 1,600 mm | |
Hydraulic System Oil Pressure | 32 MPa | |
Delivery Pipe Diameter | 125 mm | |
End Hose Length | 3 m | |
End Hose Diameter | 125 mm | |
Chassis Parameters | Chassis Brand | SANY |
Engine Max. Net Power | 244 kW / 1,900 rpm | |
Emission Standard | China V | |
Fuel Tank Capacity | 400 L | |
Engine Displacement | 8.7 L | |
Maximum Speed | 85 km/h |





1:What are your main export construction machineries?
A:Used concrete mixer truck,Used trailer concrete pump,Used concrete
line pump,Used Truck mounted concrete pump,Concrete batching plant,used cranes,used excavators,used road machinery, used piling machinery and so on.Ranging second-hand original machineries to refurbished machineries .
2:Is your company a factory or a trader?
A:We are re-manufacturing factory with a big used construction
machinery trading platform.we specialize in construction machinery
wholesale and concrete machinery re-manufacturing for more than 13
years.
3:What are the advantages of re-manufacturing machineries and what
quality of your refurbished machineries?
A:The big advantage is price of used machine,value of new machine.We
set the highest maintenance and re-manufacturing standard
system,strictly inspect and repair according to the standard,Our
each re-manufacturing will go through 14 processes from admission
test to final inspection to make sure the best quality.
4:How do I know the condition of the original used or
re-manufacturing concrete pump truck?
A: We will provide a video of the specifications and the test of
the pump truck before we ship to you.
5:What is the minimum order quantity for your used machinery?
A: The MOQ is 1 unit.
|
