| Categories | Used Truck Crane |
|---|---|
| Brand Name: | SANY |
| Place of Origin: | China |
| MOQ: | 1 |
| Price: | USD86000 - USD150000 EXW |
| Payment Terms: | L/C,T/T |
| Delivery Time: | in two weeks |
| Packaging Details: | Bulk Cargo Shipping |
| Engine model: | Weichai WP12.375E50 (China V) |
| Advantage: | Second hand price, brand new experience |
| Hydraulic Cylinder Brand: | original |
| Engine maximum power: | 276/1900 kW/rpm |
| Company Info. |
| Hunan Teila Heavy Industry Machinery Group Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Type | Item | Unit | Parameter |
Size Parameters | Overall length | mm | 14970 |
Overall width | mm | 2800 | |
Overall height | mm | 3920 | |
Weight Parameters | Overall weight | kg | 50000 |
Load on first and second axles | kg | 24000 | |
Load on third and fourth axles | kg | 26000 | |
Power Parameters | Engine model | Weichai WP12.375E50 (China V) | |
Engine maximum power | kW/rpm | 276/1900 | |
Engine maximum torque | N.m/rpm | 1800/1000-1400 | |
| Driving Parameters | Maximum travel speed | km/h | 92 |
Minimum turning radius | m | 12 | |
Approach angle | ° | ≥10 | |
Departure angle | ° | ≥14 | |
Maximum climb gradient | % | 45 | |
Fuel consumption per 100 km | L | ≤44 | |
Main Performance Parameters | Maximum rated total lifting capacity | t | 80 |
Tail swing radius | m | 4.385 | |
Maximum lifting torque (basic arm) | kN.m | 3352 | |
Maximum lifting torque (longest main arm) | kN.m | 1811 | |
Outrigger span (lateral × longitudinal) | m | 8×6.43 | |
Boom length (basic arm) | m | 12.65 | |
Boom length (longest main arm) | m | 57.6 | |
Boom length (main + auxiliary arm) | m | 84.6 | |
Working Speed Parameters | Main winch max speed (no load) | m/min | 130 |
Auxiliary winch max speed (no load) | m/min | 130 | |
Full boom extension/retraction time | s | 430/400 | |
Full boom lifting/lowering time | s | 65/90 | |
Rotation speed | r/min | 0-1.8 |





1:What are your main export construction machineries?
A:Used concrete mixer truck,Used trailer concrete pump,Used concrete
line pump,Used Truck mounted concrete pump,Concrete batching plant,used cranes,used excavators,used road machinery, used piling machinery and so on.Ranging second-hand original machineries to refurbished machineries .
2:Is your company a factory or a trader?
A:We are re-manufacturing factory with a big used construction
machinery trading platform.we specialize in construction machinery
wholesale and concrete machinery re-manufacturing for more than 13
years.
3:What are the advantages of re-manufacturing machineries and what
quality of your refurbished machineries?
A:The big advantage is price of used machine,value of new machine.We
set the highest maintenance and re-manufacturing standard
system,strictly inspect and repair according to the standard,Our
each re-manufacturing will go through 14 processes from admission
test to final inspection to make sure the best quality.
4:How do I know the condition of the original used or
re-manufacturing concrete pump truck?
A: We will provide a video of the specifications and the test of
the pump truck before we ship to you.
5:What is the minimum order quantity for your used machinery?
A: The MOQ is 1 unit.
|
