| Categories | High Voltage Battery |
|---|---|
| Brand Name: | RESUN |
| Model Number: | LV-BT-5.12Aa-3 |
| Certification: | CB, IEC62619, CE-EMC, CE-GPSD, UKCA, UL1973, UL9540A, EN62040, IEC62040; UN38.3, MSDS |
| Place of Origin: | China |
| MOQ: | 1pcs |
| Price: | Negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 10000 |
| Delivery Time: | 3-30days |
| Model: | LV-BT-5.12Aa-3 |
| Warranty: | 5 years |
| Operating Voltage: | 134.4V～168.48V |
| IP Rating: | IP65 |
| Cycle Life: | 6000 times @80%DOD |
| Battery Chemistry: | Lithium-iron phosphate (LiFePO4) |
| Certifications: | CB, IEC62619, CE-EMC, CE-GPSD, UKCA, UL1973, UL9540A, EN62040, IEC62040; UN38.3, MSDS |
| Company Info. |
| RESUN ENERGY CO,.LTD |
| Verified Supplier |
| View Contact Details |
| Product List |
| Model | LV-BT-5.12Aa-3 |
Number of layers | 3 layers |
Energy | 15.36KWh |
| Operating Voltage Range | 134.4V～168.48V |
Dimension (L*W*H)mm | 610*225*1140 |
| Weight(KG) | 170 |
| Recommend charge current | 50A |
| Max continue charge current | 100A |
| Max continue discharge current | 100A |
| Display | The information of Battery, such as SOC, battery voltage and so on |
| Communication | Support RS485 / CAN |
| Maximum parallel support | 4 clusters(3 to 6 units per cluster) |
| Charging temperature | 0℃~55℃ |
| Discharge temperature | -20℃~60℃ |
| Environment | Indoor |
| Relative humidity | 5%～95% |
| Cooling | Natural convection |
| Cell technology | Lithium-iron phosphate (LiFePO4) |
| Protection Rating | IP65 |
| Life cycle | 6000 times @80%DOD |
| Certificates | CB, IEC62619, CE-EMC, CE-GPSD, UKCA, UL1973, UL9540A, EN62040, IEC62040; UN38.3, MSDS |
| Single module Technical Specification | |
| Module | 51.2V 100Ah, 5.12kWh |
| Dimension (L*W*H)mm | High Voltage Box:610*225*250 Battery Box:610*225*250 |
| Weight(KG) | High Voltage Box:16 Battery Box:48.5 |
|
