Steel-backed bushings, also known as ptfe bushings, are a type of precision mechanical component commonly used in various industrial applications. These bushings feature a steel backing that provides excellent mechanical strength and stability, while the (Polytetrafluoroethylene) lining offers excellent chemical resistance, low friction, and long-lasting wear resistance.

The customized size option allows for precise fitment in a wide range of machinery and equipment. Wh you need bushings for high-speed rotating shafts, linear motion guides, or any other application, these bushings can be tailored to meet your specific requirements.

Manufactured in China, these steel-backed bushings offer a cost-effective solution while maintaining high quality and performance. Chinese suppliers have extensive experience in manufacturing precision mechanical components and can provide reliable products that meet international standards.

In summary, steel-backed bushings with customized sizes, supplied by China, are an excellent choice for industrial applications that require high performance and durability. Wh you're looking to replace worn-out bushings or upgrade your equipment with improved performance, these bushings are worth considering.

Self Lubricating Plain Bearing

alternative MU(SF-1,SBT)Steel Backed Bushings,high performance rings in steel, environmental protection is based on a steel substrate, medium bronze powder, a spherical sintered surface rolling four ethylene () and a mixture of green polymer material, bearing and sliding bearing . The product is lead-free environmental protection, the wear resistance performance is excellent.https://www.viiplus.com

Self-lubricating Bearings Type

• Straight bushings
• Flange bushings
• Thrust washer
• stip
• Non-standard products are also avalidable.

Structure

1. / Pb composition, 0.01-0.03 mm, anti-abrasion material, which forms a lubrication film to protect the shaft during the machine in operation.

2.bronze powder layer, 0.2-0.35 mm, which further strengthens the combination of the steel sheet and the layer. Bronze has good thermal conductivity. It can transfer the heat it produces

3.during operation more quickly.

4.Low-carbon steel, which improves load capacity and heat transfer.

5.Copper / tin coating layer, anti-corrosion.

Application

Oil-free or minimal oil condition, maintenance-free or fair need a little maintenance.
Resists abrasion, low coefficient of friction, long service life.
Operating in -190 ℃ ~ + 280 ℃.
Easy to mend, silent, non-polluting.
Thin, light wall, which can reduce the volume of the machine.
Formation of a film transferred during operation to protect the tree.
Low demand on the tree, even without surface hardness treatment, which reduces the cost of the coupling components.
No absorption to water/oil,small coefficient of thermal emption,good thermal conductivity and size stability.
The back of the steel strip can be plated with various metal,anti-corrosion.
The products now are used in sliding components of different
machines,such as auto machines,piston pump,gear pump,textile
machine,auto-sides machine,injection machine,sports machine,office

Beyond Grease: A Deep Dive into Oilless Bushings & Why Viiplus Leads the Way

Friction is the enemy of efficiency. In countless machines, from massive industrial equipment to intricate automotive components, the constant battle against wear and tear dictates performance, longevity, and maintenance costs. Traditionally, grease and oil have been the go-to solutions, but they come with their own set of challenges: frequent re-lubrication, potential contamination, environmental concerns, and limitations in extreme conditions.

Enter the world of oilless bushings, also known as self-lubricating bearings or sliding bearings. These innovative components offer a smarter way to manage friction, delivering reliable movement without the need for external lubrication.

At Viiplus (www.viiplus.com), we don't just supply these components; we engineer solutions. Leveraging deep expertise in metallurgy and tribology (the science of friction, wear, and lubrication), we've become a leading name in sliding bearing technology. But what exactly are oilless bushings, and why should they be on your radar? Let's dive deeper.

What Exactly Are Oilless Bushings? The Science of Self-Lubrication

Unlike traditional ball or roller bearings that rely on rolling elements and require constant lubrication films, oilless bushings operate on the principle of sliding motion. Their "magic" lies in their material composition and structure, designed to provide their own lubrication at the bearing surface. This can be achieved through several key technologies:

1. Solid Lubricants Embedded: Materials like graphite, MoS₂, or PTFE are embedded directly into the metallic matrix (often bronze) of the bushing. As the shaft rotates or slides, a minuscule amount of this solid lubricant is transferred to the mating surface, creating a low-friction film.

2. Porous Metal Structures: Sintered bronze or iron materials are created with microscopic pores. These pores are vacuum-impregnated with oil during manufacturing. In operation, slight heating causes the oil to expand and seep onto the bearing surface, providing lubrication. When it cools, the capillary action draws the oil back in, creating a closed-loop system.

3. Layered Composites: These often feature a strong backing (like steel), an intermediate sintered layer (like bronze), and a low-friction overlay (often PTFE-based). The PTFE layer provides the primary sliding surface, offering extremely low friction.

4.

Contrasting Logic: Oilless vs. Traditionally Lubricated Bearings

The Tangible Benefits: Why Make the Switch?

Choosing oilless bushings isn't just about eliminating grease guns. It's about unlocking significant operational advantages:

• Drastically Reduced Maintenance: This is the most obvious benefit. No re-greasing means less labor, less scheduled downtime, and simplified maintenance protocols. Imagine the savings across a factory floor!

• Enhanced Reliability: Lubricant starvation is a major cause of bearing failure. Self-lubricating bearings ensure consistent lubrication, leading to predictable performance and longer service life, especially in hard-to-reach locations.

• Superior Performance in Harsh Conditions: Oilless bushings excel where traditional lubricants fail:

  • High Temperatures: Certain types can operate at temperatures far exceeding the limits of conventional greases.

  • Low Temperatures: No grease means no stiffening or freezing issues.

  • Contaminated Environments: The absence of sticky grease reduces the ingress of dirt, dust, and debris.

  • Vacuum or Underwater: Ideal for applications where liquid lubricants are impractical or impossible.

  •
  •
  •
  •
  •
  •
  •

• Cost Savings (Total Cost of Ownership): While the initial purchase price might sometimes be higher, the TCO is often significantly lower due to savings on lubricants, labor, downtime, and potential component failure replacement.

• Environmental Friendliness: Eliminating oil and grease leakage prevents contamination of products, machinery, and the environment. Crucial for industries like food processing, pharmaceuticals, and textiles.

• Compact & Simplified Designs: Without the need for lubrication systems (nipples, lines, reservoirs), machine designs can be more compact and streamlined.

•

Exploring Viiplus's Portfolio: Finding Your Solution

Viiplus offers a comprehensive range of self-lubricating bearings designed to meet diverse application needs. Understanding the different series helps in selection:

• JDB Series (Graphite Plugged Bronze): Excellent for high-load, low-speed applications, intermittent motion, and high temperatures. The graphite plugs provide continuous solid lubrication. Ideal for heavy machinery, molds, and hydraulic components.

• SF Series (PTFE-Based Composite): Typically metal-backed (SF-1: steel, SF-2: steel/bronze) with a PTFE-based lining. Offers very low friction, good wear resistance, and suitability for dry running or marginal lubrication. Common in automotive, office equipment, and hydraulics.

• JF Series (Bimetal Bushings): Combines a steel backing with a sintered bronze or lead-bronze lining. Good load capacity and fatigue strength. Often used with grease or oil but can operate marginally lubricated. Found in engines, chassis parts, and agricultural machinery.

• FB Series (Wrapped Bronze): Often made from bronze strip, sometimes with lubrication pockets or through-holes. A cost-effective solution for medium loads and speeds, typically requiring initial greasing but offering extended re-lubrication intervals.

•

Quick Comparison Chart (General Guide):

(Note: This is a simplified guide. Always consult specific product data sheets or Viiplus experts for precise application requirements.)

Uncertain which material or type suits your project? Our Bushing Material Selection Guide is designed to help, or Contact Us for a Free Quote and Expert Advice.

Why Partner with Viiplus? Expertise Meets Quality

Choosing the right supplier is as critical as choosing the right bushing. Here’s why companies worldwide trust Viiplus:

• Deep Expertise: Our foundation in metallurgy and tribology, coupled with a talented R&D team, means we understand the science behind reliable movement. We don't just sell; we solve friction challenges.

• Uncompromising Quality: We employ advanced manufacturing techniques (including sand casting, centrifugal casting, metal casting, investment casting) and a rigorous quality management system, ensuring every bushing meets the highest standards.

• Comprehensive Range: From standard metric sizes in JDB, SF, JF, and FB series to custom solutions including cylindrical, flange, double flange bushings, wear plates, and guide rails – we have the portfolio to match your needs.

• Global Reach, Seamless Logistics: Based in China, we ship sliding bearings worldwide. Our professional team handles customs clearance efficiently, ensuring smooth, timely delivery with all necessary documentation.

• Customer-Centric Approach: We believe in ethical practices and building trust. We offer flexible production (single units to large series), competitive pricing, and  online support.

•
