| 品牌: | Bluesun |
| 型号: | BSM380P-72M |
| 原产地: | Anhui, China |
| 电池片尺寸: | 156.75mmx156.75mm |
| 类型: | 打击乐, 兆瓦 |
| 尺寸: | 1956*992*40mm |
| 组件效率: | 22% |
| Type: | Standard Solar Panel |
| Solar cell: | Poly 156x156mm |
| Certificate: | TUV/CE/ETL |
| Frame: | Anodized Aluminium Alloy |
| Junction Box: | IP65 Rated |
| Color: | Blue And Black |
| Warranty: | 25 Years Output Power Guarantee |
| OEM Order: | Acceptable |
| Front Cover: | 3.2mm High transmission, low Iron |
| 保修期: | 25 YEARS |
| Company Info. |
| Bluesun Solar Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
MWT( Metal Wrap Though) is a newly developed back contact cell
technology. It provides a new cell structure that eliminates
electrodes on the front and maximizes the utilization of light and
enhances reliability. MWT Back Contact cells converge the
electrodes from the front to the rear side using conductive paste.
This innovative design features with no bus-bar and no ribbon at
the front.

Technical Features
1.Improved Usage of Light
2.Improved Absorption of Electrodes
3.Better Response to Shading, Cracks and Breakage

Max power (Pm) (W) | 350 | 355 | 360 | 365 | 370 | 375 | 380 | ||||||
Power Tolerance (%) | 0~+3 | ||||||||||||
Max-Power Voltage (Vm) (V) | 37.5 | 37.7 | 37.9 | 38.1 | 38.3 | 38.5 | 38.7 | ||||||
Max-Power Current (Im) (A) | 9.34 | 9.42 | 9.5 | 9.59 | 9.67 | 9.75 | 9.83 | ||||||
Open-Circuit Voltage(Voc) (V) | 46.4 | 46.6 | 46.8 | 47.0 | 47.2 | 47.4 | 47.6 | ||||||
Short-Circuit Current(Voc) (A) | 9.79 | 9.86 | 9.92 | 9.98 | 10.04 | 10.10 | 10.16 | ||||||
Module Efficiency (%) | 18.1 | 18.3 | 18.6 | 18.8 | 19.1 | 19.3 | 19.6 | ||||||

We improved the initial degradation of the 1st year from -3.5% to
-2% and reduce the annual degradation rate from -0.7%/year to
-0.6%/year. Thereafter, we're proud to provide you a superior
warranty.

Model | 60 Cells Package | 72 Cells Package | ||||
Container Size | Quantity (pcs) | Quantity (pcs) | Quantity (pcs) | Quantity (pcs) | ||
20GP | 360 | 12 | 260 | 10 | ||
40GP | 840 | 28 | 624 | 24 | ||
40HC | 840 | 28 | 624 | 24 | ||

T/T | EXW | 30% T/T in advance, paid the balance before shipment | |||
FOB | |||||
CFR(C&F) | 30% T/T in advance, paid the balance against copy of B/L | ||||
CIF | |||||
L/C | L/C amount above 50,000 usd, we can accept L/C at sight | ||||
Paypal | |||||
West Union | |||||
Delivery Time | 7~10days after receiving payment for one container | ||||
