| Categories | PVDF Aluminum Composite Panel |
|---|---|
| Brand Name: | Alushang |
| Model Number: | 1220*2440MM 4MM |
| Certification: | sgs ISO |
| Place of Origin: | HENAN China |
| MOQ: | 300meter square |
| Price: | negotiable RMB/DOLLARS +square meter/pieces |
| Payment Terms: | L/C, D/A, D/P, T/T |
| Supply Ability: | 100,000 Square Meter/Square Meters per Month |
| Delivery Time: | 15-20days |
| Packaging Details: | wooden package |
| Design style: | Industrial |
| Surface treatment: | HDPE Coated |
| dimension: | 1.22*2.44m or customerized |
| After-sale Service: | Online technical support |
| Usage: | uv print/advertisement |
| Function: | PE and PVDF Coated ACP Panels |
| Size: | 1220*2440mm,customize |
| Aluminum thickness: | 0.04mm-0.5mm |
| Standard size: | 1220*2440mm |
| Core: | good PE core |
| Company Info. |
| Jixiang Siji Industrial Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Colour card


Specifications And Sizes
| Specifications and Sizes | |
| Aluminum Skin Thickness: | 0.06mm-0.50mm |
| Total Panel Thickness: | 2mm-6mm |
| Width: | 1000mm, 1220mm (regular), 1250mm, 1300mm, 1500mm, 1550mm, 1575mm, (maximum) |
| Length: | Up to 5800mm |
| Standard Size: | 1220mm (width)×2440mm (length) |
| Production Capability: | 100,000sqm / month |
| Inner core | ( Normal non-toxic polyethylene, one side unbroken polyethylene, two sides unbroken polyethylene, virgin LDPE, ) B1 non-combustible mineral filled core,A2 non-combustible mineral filled core |
| Non-standard sizes and special colors are available depending on customers' offers | |
Shipping
| Item | Details |
| Product Basics | PVDF - coated aluminum composite panel, 3 - 6MM thick, 1.22m x 2.44m |
| Packaging Process | 1. Initial Protection:Each panel is fully covered with a scratch - resistant film2. Secure Enclosure:Placed into reinforced wooden crates for maximum protection3. Clear Identification:Crates labeled with product name, dimensions, and quantity4. Extra Cushioning:All empty spaces filled with shock - absorbing materials |
Logistics Solutions | - Diverse Options:Multiple shipping methods to suit different needs- Reliable Partners:Collaborations with trusted international shipping companies- Expedited Solutions:Fast - track services for urgent orders- Monitoring:Real - time tracking to ensure on - time and intact delivery |
| Product Highlights | The PVDF coating undergoes a multi - step spraying process, offering exceptional resistance to acids, alkalis, and stains. With a high - density PE core, the panel excels in thermal insulation and soundproofing, while maintaining flexibility. Customization in thickness, size, color, and texture is available to meet unique project requirements. |
Technical Distinctions | ICoating Mastery: The PVDF finish undergoes a 5-stage application process (pretreatment, primer, basecoat, topcoat, curing), achieving a 2H pencil hardness rating and 95% gloss retention after 1,000 hours of UV exposure. |
