GOST 10498 08X18H10T AISI 321 Thin Wall Stainless Steel Tube For Corrosion Resistant

GOST 10498 08X18H10T AISI 321 Thin Wall Stainless Steel Tube For Corrosion Resistant

GOST 10498 08X18H10T AISI 321 Thin Wall Stainless Steel Tube For Corrosion Resistant
GOST 10498 08X18H10T AISI 321 Thin Wall Stainless Steel Tube For Corrosion Resistant
Categories Stainless Steel Tube
Brand Name: TORICH
Model Number: 08X18H10T
Certification: ISO,SGS,Other,ROHS
Place of Origin: Zhejiang/China
MOQ: 1Ton
Price: 800-1300 USD/Ton
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 60000 Ton/Tons per Year
Delivery Time: 20-30days upon products
Packaging Details: In bundles or in wooden boxes.
Alloy Or Not: Stainless
Corrosion Resistance: High
Mode Of Production: seamless tube
Surface: Annealed & pickled
Strength: High
Out Diameter: 6-630mm
Size: 1/4 inch
Type: Tube
Package: bunding
Product: 321 Stainless Steel Tube
Flexibility: Low
Chemical Composition: Stainless steel
Steel grade: 300 Series,200 Series,400 series,TP316,200/300 series
Application: Corrosion-Resistant
Welding line type: ERW,Seamless,Spiral Welded,TIG
Standard: GB,ASTM,DIN,AISI,JIS
Thickness: 1-100mm
Length: 1m-12m,6m or as customers' request,30mm or custom,0-12m,2.5-8m
Product name: stainless steel pipe/tube,AISI 304 stainless steel pipe,pipes,Stainless Steel Tubing,Fast Sell square stainless steel pipe price per ton
Material: 200 Series/300 Series/400series,200,202,AISI 201,400 series
Shape: square,Round.square.Rectangle,Slot,wire drawing,rectangular
Finish: Brush Polish,hairline,BA,mirror ETC,pickled
Technique: Cold Rolled Hot Rolled,Cold Drawing
Grade: 201/202/304 /304L/316/316L321/310s/410/420/430/440/439ect,201,316L,202,304L 316 316L 310s 321 321H 347 347H
Name: Seamless Stainless Steel Tubing,stainless steel telescopic tube,Stainless Steel Circular Corrugated Water Pipe
Contact Now
Company Info.
TORICH INTERNATIONAL LIMITED
Verified Supplier
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

GOST 10498 08X18H10T AISI 321 Thin Wall Stainless Steel Tube For Corrosion Resistant

GOST 10498 06X18H10T 09X18H10T 08X18H10T Thin Wall Stainless Steel Tube For Corrosion-Resistant

Material

The thin wall stainless steel tubes under GOST 10498 standard comprise primarily of three stainless steel grades: 06X18H10T, 09X18H10T, and 08X18H10T. These materials are austenitic stainless steels known for their excellent corrosion resistance, good mechanical properties, and weldability. They are widely used in the manufacture of thin-walled tubes that require high resistance to oxidizing and reducing media, commonly employed in chemical, food, and pharmaceutical industries.

Specification

  • Standard: GOST 10498
  • Grades: 06X18H10T, 09X18H10T, 08X18H10T
  • Type: Thin-walled seamless stainless steel tubes
  • Wall Thickness: Thin wall, optimized for corrosion resistance and lightweight applications
  • Surface: Pickled, bright annealed or as specified
  • Manufacturing Process: Hot or cold-rolled tubes meeting dimensional accuracy and surface finish requirements
  • Length: As per customer requirement or standard lengths (typically 4 - 6 meters)

Key Features

  • High corrosion resistance especially against oxidizing media
  • Good mechanical strength and toughness
  • Excellent weldability and formability
  • Thin wall design reduces weight while maintaining strength
  • Heat-treatable for enhanced performance (especially grade 06X18H10T)
  • Resistant to high temperatures and pressure environments

Chemical Composition

Element 06X18H10T (%) 09X18H10T (%) 08X18H10T (%)
Carbon (C) 0.06 max 0.09 max 0.08 max
Silicon (Si) 0.8 max 0.8 max 0.8 max
Manganese (Mn) 2.0 max 2.0 max 2.0 max
Phosphorus (P) 0.035 max 0.035 max 0.035 max
Sulfur (S) 0.03 max 0.03 max 0.03 max
Chromium (Cr) 17.5 - 19.5 17.0 - 19.0 17.0 - 19.0
Nickel (Ni) 9.0 - 11.0 8.0 - 10.5 8.0 - 10.5
Titanium (Ti) 0.5 - 0.7 - -
Nitrogen (N) - - -

Note: The 06X18H10T contains Titanium for stabilization, enhancing resistance against intergranular corrosion.

Mechanical Properties

Property 06X18H10T 09X18H10T 08X18H10T
Tensile Strength (MPa) 520 - 700 520 - 700 520 - 700
Yield Strength (MPa) ≥ 205 ≥ 205 ≥ 205
Elongation (%) ≥ 40 ≥ 40 ≥ 40
Hardness (HB) ≤ 200 ≤ 200 ≤ 200
Impact Toughness (KV) ≥ 35 J at 20°C ≥ 35 J at 20°C ≥ 35 J at 20°C

Steel Grade

  • 06X18H10T: Austenitic stainless steel stabilized with titanium. Equivalent to AISI 321.
  • 09X18H10T: Austenitic stainless steel, similar to AISI 304.
  • 08X18H10T: Austenitic stainless steel, close to AISI 304 with minor variation in carbon content.

Application

  • Chemical processing equipment
  • Food and beverage industry pipelines and equipment
  • Pharmaceutical industry tubing where high purity and corrosion resistance are required
  • Heat exchangers and condensers
  • Oil and gas industry components exposed to corrosive environments
  • Aerospace and automotive sectors needing lightweight corrosion-resistant tubing

Equivalent Grades

GOST Grade AISI/ASTM Equivalent EN Standard Equivalent
06X18H10T AISI 321 EN 1.4541
09X18H10T AISI 304 EN 1.4301
08X18H10T AISI 304L (similar) EN 1.4306 (close grade)






TORICH Group, an one-stop service provider of raw materials engaged in raw material production, R&D and
trade, has 30+ years of experience in the market, exported to 56 +countries, and won good reputation and
credibility among domestic and foreign customers.

The company's production plant covers an area of over 10,000 square meters, with an annual production
capacity of 50,000 tons of materials and a comprehensive trading and warehousing capacity of 100,000 tons, which can satisfy customers' personalized needs for raw materials in terms of diversity and timeliness.

The group holds shares in more than ten domestic production entities, whose main products include
seamless steel pipes ( carbon steel and stainless steel), welded pipes ( carbon steel and stainless steel), pipe fittings ( carbon steel and stainless steel), titanium (titanium tubes, titanium rods, titanium cakes, titanium plates, etc.), aluminum (aluminum tubes, aluminum rods, aluminum die casting, aluminum casting, CNC machining), and CNC deep processing of metal materials such as tubes, rods, and casting parts.

Over the past 30 years, the company has been gradually developing new technologies and materials to meet
the growing needs of customers and various diversified needs, exporting to more than 56 countries and still
increasing the number of exporting countries, aiming to help customers to solve the demand for raw materials, and to facilitate one-stop purchasing for customers.

Q: Are you trading company or manufacturer ?

A: manufacturer,also can do trading.


Q: How long is your delivery time?

A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.


Q: Do you provide samples? is it free or extra ?

A: Yes, we could offer the sample for free charge but need pay the cost of freight.


Q: What is your terms of payment ?

A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.

If you have another question, pls feel free to contact with me.
