| Categories | Road Wrecker Truck |
|---|---|
| Fuel Type: | Diesel |
| Emission Standard: | Euro 2 |
| Condition: | New |
| Transmission Type: | Manual |
| Dimensions (L x W x H) (mm): | 11260*2500*3570 |
| Place of Origin: | Hubei, China |
| Brand Name: | SCS |
| Product name: | rotator tow truck |
| Chassis brand: | Dongfeng Sinotruk Faw Bei Ben Tow |
| Driving type: | 8*4 |
| Usage: | Road Emergency Rescue |
| Warranty: | 12 Months Guarantee |
| Certificate: | CCC ISO9001 |
| Lifting weight: | 20ton 30ton 40ton 50ton |
| Engine model: | WD615.47 |
| Winch: | 2*15 Tons KN |
| Color: | Customized |
| Price: | CN¥322,127.69/units >=1 units |
| Company Info. |
| Hubei Runli Special Automobile Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |




Cabin | A/C installed,2~3 persons,LHD | |
Model | SCS5310TQZZ | |
No load(kg) | Total Weight(kgs) | 31000 |
Kerb weight(kgs) | 28000 | |
Front axle | VGD95 drum brake | |
Rear axle(double) | MCP16ZG | |
Full load | Max. Overall Weight | 30000 |
Overall Dimensions(mm) | Length | 11550 |
Width | 2500 | |
Height | 3570 | |
Wheel base(mm) | 1950+3625+1375+1350mm | |
Driving Model | 10*4 | |
Tyre | 12.00R20 | |
Tank dimension | 400 | |
Engine | Model | MC11.44-60 |
Power(kw) | 324 | |
Displacement(mL) | 11596 | |
Transmission | HW19712,12 forwards&1 reverses | |
Wrecker Equipment | |||
Max. Towing Weight(kg) | 50000 | ||
Lifting System | Max. Lifting Weight(kg) | 25000 | |
Max. Lifting Weight under all extension(kg) | 9500 | ||
Lifting Weight in Situ(kg) | 18000 | ||
Max. Ground Distance(mm) | 900 | ||
Hoisting System | Max. Hoisting Weight(kg) | 38000 | |
Max. Hoisting Weight under all extension(kg) | 8000 | ||
Extension Distance of Oil Cylinder(mm) | 6000 | ||
Length of crane Arm(mm) | 12000 | ||
Max. Hoisting Height(mm) | 6500 | ||
Winch | No. | 2 | |
Curb Traction/Per(KN) | 100x2 | ||
DN of Steel Rope(mm) | 20 | ||
Length of Steel Rope(m) | 45*2 | ||
Min. Line Speed(m/min) | 5 | ||
Outrigger | No. | 2 | |
Outrigger Span(mm) | 1440 | ||
Landing Strength(KN) | 80*2 | ||
Crane | 360°rotate with three arms | ||
Lifting Forks | 4 pairs | ||
Lifting fork base | 1 pair | ||
Jump-start cables | 12~24 Volts | ||
Electric system | Rear working lamp(stop,tail,turning) | 3 | |
Revolving beacon | 1 | ||
Lamps for license plate/warning lamp | 1 set | ||




|
