| Categories | Diaphragm Air Compressor |
|---|---|
| type: | L-shape Diaphragm compressor |
| configuration: | Other |
| power source: | AC Power |
| place of origin: | Jiangsu, China |
| brand name: | ChunMiao |
| model number: | GL165 |
| voltage: | Customized |
| dimension(l*w*h): | 3500x2300x2550 |
| warranty: | 1 Year |
| machinery test report: | Not Available |
| video outgoing-inspection: | Provided |
| core components: | Other |
| gas type: | Air |
| Weight (KG): | 9000 |
| Cooling Method: | WATER COOLED |
| Price: | CN¥16,054.41/pieces >=1 pieces |
| Company Info. |
| Nanjing Weili Electronic Materials Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Model | Volume flow Nm³/h | Inlet pressure MPa | Exhaust pressure MPa | Revolutions rpm | Motor power kW | Cooling water flow m³/h | Dimensions (L×W×H)mm | Weight ton |
GL165/0.3/20 | 90-300 | 0.3-1.0 | 20 | 360 | 37-75 | ≤6.0 | 3500×2300×2550 | 9 |
GL165/0.3/25 | 75-250 | 0.3-1.2 | 25 | 360 | 37-75 | ≤6.0 | 3500×2300×2550 | 9 |
GL165/1/25 | 200-300 | 1.0-1.5 | 25 | 360 | 37-75 | ≤6.0 | 3500×2300×2550 | 9 |
GL165/0.3/35 | 55-210 | 0.3 -1.2 | 35 | 360 | 37-75 | ≤6.0 | 3500×2300×2550 | 9 |
|
