| Categories | Johnson Vee Wire Screen |
|---|---|
| Brand Name: | Heng Yuan |
| Model Number: | 12-3/4" 10-3/4" 8-5/8" 6-5/8" |
| Certification: | ISO9000 |
| Place of Origin: | Hengshui,Hebei,China |
| MOQ: | 1pcs |
| Price: | Negotiation |
| Payment Terms: | L/C,L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Supply Ability: | 1000pcs/Month |
| Delivery Time: | 10 work days |
| Packaging Details: | Plastic film |
| Name: | Wire Wrapped Screen |
| Material: | Stainless steel and low carbon steel |
| Diameter: | 114-500mm |
| Length: | upto 6000mm |
| Slot size: | 0.05-100mm |
| Wrap wire: | 1.5*2mm, 2*3mm, 2*3.5mm, 2.2*3.5mm,3*5mm |
| Support rod: | ø4.0mm and others |
| End connection: | male/female threaded |
| Package: | Plastic film |
| Use: | In water wells for sand control |
| Company Info. |
| Anping County Hengyuan Hardware Netting Industry Product Co.,Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
| Attribute | Value |
|---|---|
| Name | Johnson Vee-Shaped Wire Wrapped screen |
| Material | Stainless steel and low carbon steel |
| Diameter | 114-500mm |
| Length | upto 6000mm |
| Slot size | 0.05-100mm |
| Wrap wire | 1.5*2mm, 2*3mm, 2*3.5mm, 2.2*3.5mm, 3*5mm,3*6mm |
| Support rod | ø4.0mm and others |
| NO. of rods | we will make it according to the diameter |
| End connection | Male/female threaded, welded rings |
| Surface | Polished |
| Package | Plastic film |
| Use | In water wells for sand control |
Name: Wire-Wrap screen, Continuous Slot Water Well Screen, Johnson screen, Water wire screen, Wedge wire screen, Screen tube, Slotted tube, Wound screen, Continuous slot screen filter, Sand control screen, Wedge wire screen pipe, Rotary filter drum, Oil screen.
Material: Stainless steel 202, 304, 304L, 316L, Non-magnetic Stainless steel, Low carbon galvanized etc.
Diameter: 3", 4", 6", 8", 10", 12", 14", 16", 18" etc.
Slot: From 0.1-100mm (Normal slot 0.5mm, 0.63mm, 0.75mm, 1.0mm, 1.5mm)
Length: From 100-6000mm (Normal length is 2.9m/3m and 5.8m/6m, to fit container)
Wrap wire: 2*3.5mm, 2.2*3.5mm, 3*4.6mm, 3*5mm, 3*6mm, 3*6.5mm, 3.2*6mm, 4*7mm etc.
Support rod: ø3.0-ø6.0mm round wire, Also can be Vee-shaped wire.
Ends: Welded rings/Plain beveled ends, Male/female threaded, Flange etc.
Use: Water Well, Oil Wells, Waste Water Treatment, Water supply systems, Coal & Mine, Food Processors & Beverage Screens, Environmental protection, Refining & Petrochemical, Architecture & Construction etc.
| Sizes (inch) | OD (mm) | Slot (mm) | Length (m) | Tensile Strength | Collapse Strength | Wrap wire Vee-shaped wire (mm) | Support rod Round wire (mm) |
|---|---|---|---|---|---|---|---|
| 3-1/2 | 88.9 | 1.0 | 2.9 | ＞22 | 10.2 | 2.0*3.5(Width*height) | ø3.8MM×22 |
| 4-1/2 | 114.3 | 1.0 | 2.9 | ＞28 | 11.5 | 2.0*3.5(Width*height) | ø3.8MM×22 |
| 6-5/8 | 168.3 | 0.75 | 5.8 | ＞40 | 12.8 | 2.0*3.5(Width*height) | ø3.8MM×32 |
| 6-5/8 | 168.3 | 1.0 | 5.8 | ＞33 | 12.8 | 2.2*3.5(Width*height) | ø3.8MM×32 |
| 6-5/8 | 168.3 | 0.63 | 5.8 | ＞83 | 45 | 3.0*6.0(Width*height) | ø6.0MM×32 |
| 8-5/8 | 219.1 | 1.0 | 5.8 | ＞34 | 21.9 | 2.2*3.5(Width*height) | ø3.8MM×48 |
| 8-5/8 | 219.1 | 1.0 | 5.8 | ＞50 | 38.2 | 3.0*4.6(Width*height) | ø4.0MM×48 |
| 8-5/8 | 219.1 | 1.0 | 5.8 | ＞60 | 46 | 3.0*6.0(Width*height) | ø5.0MM×48 |
| 10-3/4 | 273.1 | 0.75 | 5.8 | ＞50 | 32.9 | 2.2*3.5(Width*height) | ø4.0MM×55 |
| 10-3/4 | 273.1 | 1.0 | 5.8 | ＞60 | 39.5 | 3.0*4.6(Width*height) | ø4.8MM×55 |
| 10-3/4 | 273.1 | 1.0 | 5.8 | ＞100 | 48 | 3.2*6.0(Width*height) | ø5.0MM×55 |
| 12-3/4 | 323.9 | 1.0 | 5.8 | ＞120 | 37.2 | 3.0*5.0(Width*height) | ø4.0MM×56 |
| 14 | 355.6 | 1.0 | 2.9 | ＞80 | 37.8 | 3.0*5.5(Width*height) | ø4.0MM×59 |
| 16 | 426 | 1.0 | 2.9 | ＞80 | 37.5 | 3.0*5.5(Width*height) | ø4.0MM×64 |
Special specification can be made according to your need.
|
