| Categories | Magnetic RJ45 Jack |
|---|---|
| Brand Name: | LINK-PP |
| Model Number: | 7498111124 |
| Certification: | ISO9001,SGS,UL,CE,REACH |
| Place of Origin: | GuangDong, China |
| MOQ: | 50/500/1000/25K |
| Price: | $0.3-$2.8 |
| Payment Terms: | TT,NET30/60/90 Days |
| Supply Ability: | 3000000/Month |
| Delivery Time: | About 1-2 Days |
| Packaging Details: | Tray |
| Mount: | Through Hole Reflow |
| PoE: | non-PoE |
| Tab Direction: | Tab Down |
| Speed: | 1000BASE-T |
| LED L / R Color: | Yellow-Green |
| EMI Tabs: | With |
| RoHS Compliant: | Support |
| Operating Temperature: | -40 °C up to +85 °C |
| Inductance: | 350 µH (min) |
| Turns Ratio: | 1:1 |
| Company Info. |
| LINK-PP INT'L TECHNOLOGY CO., LIMITED |
| Verified Supplier |
| View Contact Details |
| Product List |
The 7498111124 is a WE-RJ45LAN series Through Hole Reflow RJ45 Connector with integrated magnetics, suitable for 1000BASE-T Ethernet applications. This product complies with IEEE 802.3ab standards and is RoHS and REACH compliant.
| Specification | Details |
|---|---|
| Connector Type | THR RJ45 Magnetic Connector |
| Number of Ports | 1 |
| Part Number | 7498111124 |
| Speed | 10/100/1000Base-T |
| Tab | Down |
| PoE | Non |
| Improved CMRR | NO |
| Shielding | Shielded With EMI Fingers |
| Mounting Type | Through-Hole Reflow |
| LED Indicators | yellow-green LEDs |
| Operating Temperature | -40 °C up to +85 °C |
| Compliance | IEEE 802.3, RoHS |
| Applications | EtherCAT or Profinet, as well as hubs, routers, switches, IP cameras, and IoT applications. |
|
