Grade 926 Super Austenitic Stainless Steel Strip UNS N08926 Standard SS Strip
Products Specification
| Product Name | Stainless Steel Strips |
| Length | As required |
| Width | 3mm-1219mm or as required |
| Thickness | 0.15 - 3.0mm or as required |
| Standard | AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc. |
| Technique | Hot rolled / cold rolled |
| Surface Treatment | 2B or according to customer requirement |
| Thickness tolerance | ±0.01mm |
| Material | 201, 202, 301, 302, 303, 304, 304L, 304H, 310S, 316, 316L, 317L, 321,310S 309S, 410, 410S,420, 430, 431,434, 440A,904L,2205,2507,926 |
| Application | It is widely used in high temperature applications, medical devices, building materials, chemistry, food industry, agriculture, ship components.It also applies to food, beverage packaging, kitchen supplies, trains, aircraft, conveyor belts, vehicles, bolts, nuts, springs, and screen. |
| MOQ | 1tons.We also can accept sample order. |
| Shipment time | Within 15-20 workdays after receiving deposit or L/C |
| Export packing | Waterproof paper, and steel strip packed.Standard Export Seaworthy Package.Suit for all kinds of transport,or as required |
| Capacity | 250,000 tons/year |
Alloy 926 is a super-austenitic stainless steel enhanced with high molybdenum (6.0–7.0%), nitrogen (0.15–0.25%), and nickel (24–26%). Designed for extreme corrosive environments, it bridges the gap between standard austenitic steels (e.g., 316L) and high-cost nickel alloys. Its key features include:
Exceptional corrosion resistance in chloride-rich media (e.g., seawater, acids)246.
High strength and ductility due to nitrogen strengthening18.
Applications span marine engineering, chemical processing, and pollution control systems510.
| Element | Composition (%) | Role |
|---|---|---|
| Ni | 24.0–26.0 | Stabilizes austenite; boosts acid resistance |
| Cr | 19.0–21.0 | Forms passive oxide layer |
| Mo | 6.0–7.0 | Enhances pitting/crevice corrosion resistance |
| N | 0.15–0.25 | Increases strength; improves localized corrosion resistance |
| Cu | 0.5–1.5 | Resists sulfuric acid |
| Fe | Balance | Base material |
| Minor elements: C ≤0.02%, Mn ≤2.0%, Si ≤0.5%168 |
| Property | Value |
|---|---|
| Density | 8.1 g/cm³ |
| Melting Point | 1320–1390 °C |
| Tensile Strength (Rm) | ≥650 MPa |
| Yield Strength (RP0.2) | ≥295 MPa |
| Elongation (A5%) | ≥35% |
| Hardness (RB) | ≤86 |
| Data at room temperature (after solution annealing)158 |
| Environment | Performance |
|---|---|
| Seawater/Chlorides | Resists pitting/crevice corrosion (PREN >40)46 |
| Acids | Excellent in H<sub>2</sub>SO<sub>4</sub>, H<sub>3</sub>PO<sub>4</sub>, organic acids69 |
| Stress Corrosion Cracking (SCC) | Resists Cl<sup>-</sup>-induced SCC18 |
| *Validated in FGD systems (Cl<sup>-</sup> 10,000–70,000 ppm, 50–68°C)9* |
Alloy 926 strip complies with global standards for chemical composition, mechanical properties, and fabrication:
| Standard Type | Applicable Codes |
|---|---|
| Material Standards | ASTM B168 (plate/sheet), ASTM B906 (strip), EN 1.4529, UNS N0892628 |
| Fabrication Certifications | ASME Sec. VIII, VdTÜV (196–400°C)18 |
| Welding Fillers | ERNiCrMo-3 (Alloy 625), ERNiCrMo-1268 |
926 stainless steel strip is supplied in cold-rolled, solution-annealed, and descaled conditions. Common dimensions include:
| Parameter | Range |
|---|---|
| Thickness | 0.1–5.0 mm |
| Width | 10–2000 mm |
| Surface Finish | No. 1 (annealed), 2B (smooth), BA (bright annealed)59 |
| Other forms: Sheets, coils, foil (custom widths/lengths available) |
Corrosion Superiority: Outperforms 904L, 316L, and duplex steels in chloride/sulfide media410.
Cost Efficiency: Economical alternative to nickel alloys (e.g., Hastelloy) in marine/chemical systems210.
Mechanical Robustness: 35% elongation enables deep drawing; high strength allows thinner sections89.
Weldability: Maintains corrosion resistance post-welding with proper fillers68.
Alloy 926 strip is critical in:
| Industry | Specific Use Cases |
|---|---|
| Marine Engineering | Seawater piping, desalination plants (RO membranes), shipboard systems410 |
| Pollution Control | FGD scrubbers, ducting, chimneys710 |
| Chemical Processing | Heat exchangers, reactors, acid storage tanks59 |
| Oil & Gas | Polished rods for corrosive wells, subsea components48 |
| Energy | Condensers using wastewater cooling57 |
Key Suppliers: Shanghai Baoyuan Steel59, Shanghai Weili Metal7.
Handling Tips:
Avoid sulfur contamination during heat treatment (max 0.1% in fuel)8.
Cold working >15% requires re-solution annealing8.
For detailed specifications or testing reports, consult manufacturer datasheets or standards (e.g., ASTM B168, EN 1.4529).
|
