| Categories | LiFePO4 Lithium Battery |
|---|---|
| Brand Name: | Ecolite |
| Model Number: | 51.2v 105Ah |
| Place of Origin: | China |
| MOQ: | 50pcs |
| Price: | Inquiry |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 3000 units/month |
| Delivery Time: | 5-8 work days |
| Packaging Details: | Carton Pallet Container |
| Rated Voltage: | 51.2V |
| Rated Capacity: | 105Ah |
| Energy: | 5376Wh |
| Housing Protection: | IP67 |
| Efficiency: | ≥0.98 |
| Cycle Life（25℃，0.5C/0.5C，100%DOD）: | ＞4000cycles Remaining capacity＞80% |
| Weight: | 46kg |
| Self Discharge: | ＜5% per Month |
| Dimension(L×W×H): | 460mm×334mm×247mm |
| Company Info. |
| HEFEI ECOLITE ENERGY CO., LTD. |
| Verified Supplier |
| View Contact Details |
| Product List |
Features
Lithium Iron Phosphate(LiFePO4).
The Safest Lithium Technology.
Integrated Battery Management System(BMS).
Support Parallel connection of multiple batteries.
Performance
Long Cycle Life ＞4000cycles, Remaining capacity ＞ 80%@25℃,0.5C/0.5,100%DOD.
High Density,High Discharge Current,High
Temperature Range. Low Weight,Free Maintenance.
Fast Charging.
Environment Friendly.
Specification
| Mechanical Parameters | ||
| No | Item | Data |
| 1 | Dimension(W×D×H) | 460×334×247mm(18.11×13.15×9.72'') |
| 2 | Products Weight | 46kg |
| 3 | Terminal Type | FCC1020,200A |
| 4 | Battery Housing | SPCC |
| 5 | Housing Protection | IP67 |
| 6 | Cell Type-Chemistry | LifePo4Cell |
| 7 | Communication | RS485/CAN |
| Discharge Parameters | ||
| No | Item | Data |
| 1 | Continuous Discharge Current | 150A |
| 2 | Pulse Discharge Current | 250A(＜120S) |
| 3 | Recommended Volt. Disconnect | 40V |
| 4 | BMS Discharge Cut-off Voltage | 40V |
| 5 | Reconnect Voltage | 43.2V |
| 6 | Short Circuit Protection | 300-800us |
| Charge Parameters | ||
| No | Item | Data |
| 1 | Charge Method | CC-CV |
| 2 | Charge Voltage | 56.8～58.4V |
| 3 | Recommended Float Voltage | 53.2~53.6V@100% |
| 4 | Recommended Charge Current | 52.5A |
| 5 | Maximum Charge Current | 105A |
| 6 | BMS Charge Cut-off Voltage | 58.4V |
| Temperature Parameters | ||
No | Item | Data |
| 1 | Discharge Temperature | -30 ℃ to 65 ℃ |
| 2 | Charge Temperature | -30 ℃to 65 ℃,Start heating at ＜0℃ |
| 3 | Storage Temperature | 0 ℃ to 35 ℃ |
| 4 | BMS High Temperature Cut-off | 65℃ |
The product is equipped with VENT, METER, positive electrode interface, RS485, negative electrode interface, and MAIN SWITCH function interface.
VENT:Used to discharge gas inside the battery to ensure stable internal
pressure of the battery during use.
METER:Generally, it is connected to a battery power display meter to
facilitate real-time viewing of the power status of the lithium
battery.
+:Used to connect external circuits to realize functions such as
external power supply.
-:Used to connect external circuits to realize functions such as
external power supply.
MAIN SWITCH:Main switch interface, used to control the on and off of the
battery system.
FAQ
Q: where will this battery be used for ?
A: it suit for electric bicycle, scooter, motor cycle as starter
power.
Q: what is the warranty
A: 1year
Q: what is the lead time ?
A: Depends on your quantity
Q: what is your payment term ?
A: T/T(30% deposit, balance before shipment. ) and L/C
Q: Can test sample before bulk order ?
A: Yes we provide sample for testing as you request
Q: accept OEM order ?
A: 100% customized solution for you .
