JIS G7219 TS360 Seamless Pressure Pipe Seamless Steel Tubes For Pressure Purposes

JIS G7219 TS360 Seamless Pressure Pipe Seamless Steel Tubes For Pressure Purposes

JIS G7219 TS360 Seamless Pressure Pipe Seamless Steel Tubes For Pressure Purposes
JIS G7219 TS360 Seamless Pressure Pipe Seamless Steel Tubes For Pressure Purposes
Categories Seamless Steel Tube
Brand Name: TORICH
Model Number: JIS G7219
Certification: CE,ISO
Place of Origin: Zhejiang/China
MOQ: 1 Ton
Price: Negotiable
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 60000 Ton/Tons per Year
Delivery Time: 20-40days
Packaging Details: In bundles or in wooden boxes.
Standard2: Seamless Steel Tube
Thickness: 2 - 70 mm
Standard: ASTM,DIN,GB,JIS
Grade: TS360 TS410 TS430 TS500
Application: Pressure Purposes
Section shape: Round,Square
Alloy or not: Non-alloy
Technique: Hot Rolled,Cold Drawn,Cold Rolled
Outer diameter(round): 8 - 100 mm
Special pipe: precision seamless pipe,seamless stainless steel tube
Material: Carbon steel
Length: 5-12M or as your requirement
Usage: Pressure Purposes
Shape: Square. Rectangular.Round
Product name: Seamless steel tube
Surface: Customers't Requirement
Secondary or not: Non-secondary
Contact Now
Company Info.
TORICH INTERNATIONAL LIMITED
Verified Supplier
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

JIS G7219 TS360 Seamless Pressure Pipe Seamless Steel Tubes For Pressure Purposes

JIS G7219 TS360 TS410 TS430 TS500 Seamless Pressure Pipe: Seamless Steel Tubes for Pressure Purposes

Material

JIS G7219 specifies the requirements for seamless steel tubes used for pressure purposes. These tubes are designed to withstand high pressure and are commonly used in industries such as oil and gas, petrochemicals, and power generation. The seamless construction ensures uniformity and strength, making them ideal for critical applications.

Specification

The JIS G7219 standard covers several grades, including TS360, TS410, TS430, and TS500. Each grade has specific mechanical and chemical properties tailored to different pressure and temperature conditions. The tubes are manufactured using high-quality steel and advanced production techniques to ensure durability and reliability.

Key Features

  • High Strength: Designed to withstand high pressure and temperature.
  • Corrosion Resistance: Suitable for use in harsh environments.
  • Uniformity: Seamless construction ensures consistent quality.
  • Versatility: Available in various grades to suit different applications.
  • Durability: Long service life with minimal maintenance.

Chemical Composition

The chemical composition of the JIS G7219 seamless steel tubes is crucial for their performance. Below is a table presenting the typical chemical composition for each grade:

Element TS360 TS410 TS430 TS500
Carbon (C) 0.20% max 0.22% max 0.25% max 0.28% max
Silicon (Si) 0.35% max 0.35% max 0.35% max 0.35% max
Manganese (Mn) 0.90% max 1.00% max 1.10% max 1.20% max
Phosphorus (P) 0.035% max 0.035% max 0.035% max 0.035% max
Sulfur (S) 0.035% max 0.035% max 0.035% max 0.035% max

Mechanical Properties

The mechanical properties of these tubes determine their suitability for various pressure applications. The table below outlines the mechanical properties for each grade:

Property TS360 TS410 TS430 TS500
Tensile Strength (MPa) 360 min 410 min 430 min 500 min
Yield Strength (MPa) 235 min 245 min 275 min 325 min
Elongation (%) 20 min 18 min 16 min 15 min

Steel Grade

The JIS G7219 standard includes several steel grades, each designed for specific pressure and temperature conditions. The grades TS360, TS410, TS430, and TS500 offer a range of mechanical and chemical properties to meet diverse industrial needs.

Application

These seamless steel tubes are used in various applications, including:

  • Oil and Gas Industry: For transporting oil, gas, and other fluids under high pressure.
  • Petrochemical Plants: In processing units where high-pressure resistance is essential.
  • Power Generation: In boilers and heat exchangers.
  • Chemical Processing: For handling corrosive and high-pressure chemicals.

Possible Alternative Grades

While JIS G7219 provides a robust solution for pressure applications, alternative grades may be considered based on specific requirements:

  • ASTM A106: A widely used standard for seamless carbon steel pipes for high-temperature service.
  • EN 10216: European standard for seamless steel tubes for pressure purposes.
  • API 5L: Specification for line pipe suitable for conveying gas, water, and oil.

TORICH Group, an one-stop service provider of raw materials engaged in raw material production, R&D and
trade, has 30+ years of experience in the market, exported to 56 +countries, and won good reputation and
credibility among domestic and foreign customers.
The company's production plant covers an area of over 10,000 square meters, with an annual production
capacity of 50,000 tons of materials and a comprehensive trading and warehousing capacity of 100,000 tons, which can satisfy customers' personalized needs for raw materials in terms of diversity and timeliness.
The group holds shares in more than ten domestic production entities, whose main products include
seamless steel pipes ( carbon steel and stainless steel), welded pipes ( carbon steel and stainless steel), pipe fittings ( carbon steel and stainless steel), titanium (titanium tubes, titanium rods, titanium cakes, titanium plates, etc.), aluminum (aluminum tubes, aluminum rods, aluminum die casting, aluminum casting, CNC machining), and CNC deep processing of metal materials such as tubes, rods, and casting parts.
Over the past 30 years, the company has been gradually developing new technologies and materials to meet
the growing needs of customers and various diversified needs, exporting to more than 56 countries and still
increasing the number of exporting countries, aiming to help customers to solve the demand for raw materials, and to facilitate one-stop purchasing for customers.

Q: Are you trading company or manufacturer ?

A: manufacturer,also can do trading.

Q: How long is your delivery time?

A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples? is it free or extra ?

A: Yes, we could offer the sample for free charge but need pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.

If you have another question, pls feel free to contact with me.
