DIN 1626 St37 Cold Drawn Seamless Steel Pipe Carbon Steel Tube For Low Temperature Pressure

DIN 1626 St37 Cold Drawn Seamless Steel Pipe Carbon Steel Tube For Low Temperature Pressure

DIN 1626 St37 Cold Drawn Seamless Steel Pipe Carbon Steel Tube For Low Temperature Pressure
DIN 1626 St37 Cold Drawn Seamless Steel Pipe Carbon Steel Tube For Low Temperature Pressure
Categories Precision Steel Tube
Brand Name: TORICH
Model Number: DIN 1626
Certification: ISO9001-2008
Place of Origin: Zhejiang/China
MOQ: 1 Ton
Price: Negotiable
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 60000 Ton/Tons per Year
Delivery Time: 20-40days
Packaging Details: In bundles or in wooden boxes.
Standard: DIN
Thickness: 0.1mm-60mm
Technique: Cold Drawn,Hot Rolled,Cold Rolled
Alloy or not: Is Alloy
Standard2: DIN 1626
Section shape: Round,Rectangular
Outer diameter(round): 17 - 660 mm
Special pipe: Precision steel tube,precision seamless pipe,cold drawn
Secondary or not: Non-secondary
Grade group: ST35-ST52
Length: 6M or as requirement
Product name: steel tubes
Type: Seamless
Steel grade: 300 Series,200series 300series
Material: steel
Contact Now
Company Info.
TORICH INTERNATIONAL LIMITED
Verified Supplier
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

DIN 1626 St37 Cold Drawn Seamless Steel Pipe Carbon Steel Tube For Low Temperature Pressure

DIN 1626 St37 St44 St37 St42 St45 Cold Drawn Seamless Steel Pipe Carbon Steel Tube For Low Temperature Pressure

Introduction

DIN 1626 is a standard that specifies the requirements for cold drawn seamless steel pipes made from carbon steel, particularly designed for low-temperature pressure applications. This article provides an overview of the material specifications, key features, chemical composition, mechanical properties, steel grades, applications, and possible alternative grades.

Material Specification

The DIN 1626 standard covers various grades of carbon steel pipes, including St37, St44, St42, and St45. These materials are characterized by their excellent mechanical properties and suitability for low-temperature environments.

Key Features

  • Seamless Construction: Ensures uniformity and strength.
  • Cold Drawn: Enhances dimensional accuracy and surface finish.
  • Low-Temperature Resistance: Suitable for applications in cold environments.
  • High Strength: Capable of withstanding high pressure.

Chemical Composition

Steel Grade C (%) Si (%) Mn (%) P (%) S (%)
St37 0.17 0.25 1.20 0.045 0.045
St44 0.20 0.25 1.40 0.045 0.045
St42 0.20 0.25 1.20 0.045 0.045
St45 0.25 0.25 1.60 0.045 0.045

Mechanical Properties

Steel Grade Yield Strength (MPa) Tensile Strength (MPa) Elongation (%)
St37 235 360-510 26
St44 275 410-550 24
St42 245 400-550 22
St45 295 450-600 20

Steel Grade

The primary steel grades covered under DIN 1626 include:

  • St37: Low carbon steel, good weldability.
  • St44: Medium carbon steel, higher strength.
  • St42: Similar to St37 but with improved mechanical properties.
  • St45: Higher carbon content, suitable for more demanding applications.

Application

DIN 1626 seamless steel pipes are widely used in various industries, including:

  • Oil and Gas: For pipelines and pressure vessels.
  • Chemical Industry: In reactors and heat exchangers.
  • Construction: Structural applications requiring high strength.
  • Cryogenic Applications: Suitable for low-temperature environments.

Possible Alternative Grades

In addition to the specified grades, the following alternative grades may be considered based on specific requirements:

  • ASTM A106: Standard specification for seamless carbon steel pipes for high-temperature service.
  • ASTM A53: Standard specification for pipe, steel, black and hot-dipped, zinc-coated, welded, and seamless.
  • EN 10216: European standard for seamless steel tubes for pressure purposes.

TORICH Group, an one-stop service provider of raw materials engaged in raw material production, R&D and
trade, has 30+ years of experience in the market, exported to 56 +countries, and won good reputation and
credibility among domestic and foreign customers.
The company's production plant covers an area of over 10,000 square meters, with an annual production
capacity of 50,000 tons of materials and a comprehensive trading and warehousing capacity of 100,000 tons, which can satisfy customers' personalized needs for raw materials in terms of diversity and timeliness.
The group holds shares in more than ten domestic production entities, whose main products include
seamless steel pipes ( carbon steel and stainless steel), welded pipes ( carbon steel and stainless steel), pipe fittings ( carbon steel and stainless steel), titanium (titanium tubes, titanium rods, titanium cakes, titanium plates, etc.), aluminum (aluminum tubes, aluminum rods, aluminum die casting, aluminum casting, CNC machining), and CNC deep processing of metal materials such as tubes, rods, and casting parts.
Over the past 30 years, the company has been gradually developing new technologies and materials to meet
the growing needs of customers and various diversified needs, exporting to more than 56 countries and still
increasing the number of exporting countries, aiming to help customers to solve the demand for raw materials, and to facilitate one-stop purchasing for customers.

Q: Are you trading company or manufacturer ?

A: manufacturer,also can do trading.

Q: How long is your delivery time?

A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples? is it free or extra ?

A: Yes, we could offer the sample for free charge but need pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.

If you have another question, pls feel free to contact with me.
