UNS S31653 / 316LN Stainless Steel Plate EN 1.4406 SS Plate

UNS S31653 / 316LN Stainless Steel Plate EN 1.4406 SS Plate

Products Specification

316LN stainless steel plate introduction

316LN stainless steel is a low carbon, high nickel, high chromium austenitic stainless steel with excellent corrosion resistance and mechanical properties. It adds nitrogen on the basis of 316L stainless steel to further improve strength and corrosion resistance, especially for high-corrosion environments.

Main parameter
Chemical composition (typical value, %) :

• Carbon (C): ≤0.03
• Silicon (Si): ≤1.00
• Manganese (Mn): ≤2.00
• Phosphorus (P): ≤0.045
• Sulfur (S): ≤0.030
• Chromium (Cr): 16.0-18.0
• Nickel (Ni): 10.0-14.0
• Molybdenum (Mo): 2.0-3.0
• Nitrogen (N): 0.10-0.16

Mechanical properties of 316LN Stainless Steel Plate

• Tensile strength: ≥515 MPa
• Yield strength: ≥205 MPa
• Elongation: ≥40%
• Hardness: ≤217 HB

Physical properties of 316LN Stainless Steel Plate

• Density: 7.98 g/cm³
• Melting point: 1375-1400 °C
• Coefficient of thermal expansion: 16.5μm /m·°C (20-100 °C)
• Thermal conductivity: 16.3W /m·K (100 °C)
• Resistivity: 0.74 μΩ·m

Standard of 316LN Stainless Steel Plate

• ASTM: ASTM A240/A240M
• EN: EN 10088-2
• JIS: JIS G4304
• GB: GB/T 4237

Specification of 316LN Stainless Steel Plate

• Thickness: 0.5mm-100mm
• Width: 1000mm-2000mm
• Length: 2000mm-6000mm
• Surface treatment: 2B, BA, No.1, No.4, 8K, etc

Peculiarity of 316LN Stainless Steel Plate

• Corrosion resistance: Excellent performance in chloride and acidic environments, especially suitable for seawater and chemical environments.
• High strength: The addition of nitrogen increases strength and hardness.
• Low temperature toughness: still maintains good toughness at low temperatures.
• Machinability: Easy to weld, cut and form.
• Biocompatibility: Suitable for medical and food industries.

Apply of 316LN Stainless Steel Plate

• Chemical industry: Used to manufacture reactors, storage tanks, pipelines, etc.
• Marine engineering: applicable to seawater desalination equipment, ship components, etc.
• Nuclear industry: Used for nuclear reactor components.
• Medical equipment: for surgical instruments, implants, etc.
• Food processing: Used in food processing equipment and containers.
• Construction industry: Used for building structures in highly corrosive environments.

316LN stainless steel plate with its excellent corrosion resistance, high strength and good processing properties, widely used in chemical, Marine, nuclear industry, medical and food processing and other fields, is a typical representative of high performance stainless steel.
