| Categories | Silent Diesel Generator Set |
|---|---|
| Brand Name: | Cummins |
| Model Number: | KTA19-G9A |
| Place of Origin: | China |
| MOQ: | 1 |
| Price: | USD$21,361-27,180 |
| Payment Terms: | T/T or LC, D/P |
| Supply Ability: | 50 units per month |
| Delivery Time: | 25days |
| Packaging Details: | Wooden cases,nude packing |
| Power Factor: | 0.8(lagging) |
| Starting System: | Auto Start |
| Control Model Type: | Auto Start |
| Control Panel: | Smartgen, Deepsea, ComAp |
| Rated Output: | 20kW-1000kW |
| Engine Brand: | Cummins |
| Cooling Method: | Water Cooling |
| Generator Type: | Electric Power Silent Portable Diesel |
| Company Info. |
| JIANGSU STONE POWER CO.,LTD |
| Verified Supplier |
| View Contact Details |
| Product List |
Featuring Water Cooling technology, this Quiet Turbine Generator Kit ensures optimal performance and efficiency even under challenging conditions. The Electric Power Silent Portable Diesel Generator is equipped with a high-quality Cummins engine, known for its durability and dependability.
Whether for backup power in residential settings, construction sites, or industrial applications, this generator set delivers consistent and stable power output. The Silent Diesel Generator Set is the ideal choice for businesses and individuals looking for a reliable and efficient power solution.
| Diesel Generator Set Data | ||
| Set Type: | SC388E5 | |
| Standby Power: | 340KW/425KVA | |
| Prime Power: | 310KW/388KVA | |
| Rated Current: | 360 (A) | |
| Rated Frequency: | 50(Hz) | |
| Start-up time: | 5～6(s) | |
| Power Factor: | 0.8(Lag) | |
| Rated Voltage: | 400/230(V) | |
| Diesel Engine Data | ||
| Manufacturer: | CCEC Cummins | |
| Model: | 6ZTAA13-G3 | |
| Prime/Standby Power: | 310KW/325KW | |
| Rated Speed: | 1500(r/min) | |
| Cycle: | 4 stroke | |
| Cylinder Arrangement: | 6 in line | |
| Displacement: | 14L | |
| Bore and Stroke: | 140*152(mm) | |
| Compression Ratio: | 14:01 | |
| Governor Type: | Electronic | |
| Start battery voltage: | 24V DC | |
| Air Intake System | ||
| Air Intake System: | Turbo, Water/Air Cooling | |
| Max Intake Restriction: | 6.25kPa | |
| Burning Capacity: | 425L/s | |
| Air Flow: | 8180L/s | |
| Exhaust System | ||
| Exhaust Gas Flow: | 1126L/s | |
| Exhaust Temperature: | 563℃ | |
| Max Back Pressure: | 10kPa | |
| Fuel System | ||
| Fuel System: | PT type fuel pump | |
| 100%( Prime Power) Load: | 200g/kwh | |
| 50%( Prime Power) Load: | 203g/kwh | |
| Oil System | ||
| Total Oil Capacity: | 38.6L | |
| Oil Consumption: | ≤0.24g/kwh | |
| Engine Oil Tank Capacity: | 36L | |
| Oil Pressure at Rated RPM: | 241-345kPa | |
| Cooling System | ||
| Cooling Way: | Water-cooled | |
| Total Coolant Capacity: | 85L | |
| Thermostat: | 82-93℃ | |
| Max Water Temperature: | 104℃ | |
| Alternator Data | ||
| Manufacturer: | LEROY SOMER/STAMFORD/SIEMENS/MARATHON/ENGGA /KEPU | |
| Excitation Mode: | Brushless and self- exciting | |
| Number of phase and Access Act: | 3-phase 4-wire | |
| Connecting Type: | "Y" type connecting | |
| Alternator Capacity: | 375KVA | |
| Alternator Efficiencies: | 95% | |
| Overload: | (PRP)110% load can run 1h | |
| Protection Level: | IP22-IP23 | |
| Insulation Class, Temperature Rise: | H/H | |
| Telephone Influence Factor (TIF): | ＜50 | |
| THF: | ＜2% | |
| Voltage Regulation, Steady State: | ≤±1% | |
| Air Cooling Flow: | 0.8m3/s | |
| Altitude: | ≤1000m | |
| Genset Electrical Performance | ||
| Voltage Regulation: | ≥±5% | |
| Voltage Regulation, Stead State: | ≤±1% | |
| Sudden Voltage Warp (100% Sudden Reduce): | ≤+25% | |
| Sudden Voltage Warp (Sudden Increase): | ≤-20% | |
| Voltage Stable Time (100% Sudden Reduce): | ≤6S | |
| Voltage Stable Time (Sudden Increase): | ≤6S | |
| Frequency Regulation, Stead State: | ≤5% | |
| Frequency Waving: | ≤1.5% | |
| Sudden Frequency Warp (100% SuddenReduce): | ≤+12% | |
| Sudden Frequency Warp (Sudden Increase): | ≤-10% | |
| FrequencyRecoveryTime(100%SuddenReduce): | ≤5S | |
| FrequencyRecoveryTime(Sudden Increase): | ≤5S | |
| Options | ||
| Engine | Alternator | |
| Heater 2KW & 4KW | Anti Condensation Heater | |
| Battery Charger 3.5A & 7A | Permanent Magnet Generator(PMG) | |
| Water Separator | Drop CT(For Paralleling) | |
| Daily Fuel Tank | ||
| Fuel Level Sensor | ||
| Control System | Others | |
| Remote Control Panel | Rainproof Type | |
| Auto Transfer Switch (ATS) | Soundproof Type | |
| Paralleling System | Trailer Type | |
| Open Type | ||
| Overall Size | Weight | |
| 3030(mm)*1100(mm)*1850(mm) | 2950(kg) | |
 | ||
| Soundproof Type | ||
| Overall Size | Weight | |
| 4300(mm)*1800(mm)*2150(mm) | 4000(kg) | |
 | ||
Product Packaging:
The Silent Diesel Generator Set is carefully packaged in a sturdy cardboard box to ensure safe transportation. The set is securely fitted inside the box with protective padding to prevent any damage during shipping.
Shipping:
We offer fast and reliable shipping for the Silent Diesel Generator Set. The set will be shipped using a trusted courier service to ensure timely delivery to your location. You will receive a tracking number to monitor the status of your shipment.
|
