| Categories | Brushed Motor DC |
|---|---|
| Brand Name: | Lihua Motor/ HCS Motors |
| Model Number: | RC-260 |
| Certification: | ISO9001/Reach/RoHs/SGS/CE |
| Place of Origin: | Dongguan,China |
| MOQ: | 3000pcs |
| Payment Terms: | T/T |
| Supply Ability: | 12000pcs/Day |
| Delivery Time: | 30-45Days |
| Packaging Details: | Foam Inner /Carbon Outer |
| Motor Type: | RC-260SA-2670/RC-260RA-2670 |
| Shaft Diameter: | 2mm |
| Motor Body Size: | 24mm*26.9mm |
| Voltage: | 3V |
| Shaft Type: | Round/D Shaft |
| Operating Temperature: | -20°C To 80°C |
| Noise Level: | ＜45 dB |
| Speed: | 6000RPM/1200RPM/Or As You Request |
| Applications: | Hair Clipper/Massager/DIY Toys/Radio Control Model/Vibrator |
| Weight: | 28g |
| No-Load Speed: | 12300 rpm |
| No-Load Current: | 0.4 amps |
| Company Info. |
| Guang Dong Lihua Mechatronics Co.,Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
High Efficiency: The RC-260SA motor achieves a high speed of 12300 RPM/6900RPM at 3V, ensuring strong power and efficient performance during operation.
Compact Design: With dimensions of 24cm x 26.9cm, the motor is compact and suitable for installation in various small devices, especially in space-limited applications.
Round Shaft Design: The round shaft design offers flexible installation and compatibility with multiple transmission methods, making it ideal for DIY modifications or repairs.
Wide Applicability: This motor is not only suitable for hair clippers but also for DIY toys, model cars, small fans, and other electric devices, meeting diverse user needs.
Durability: Made from high-quality materials, the motor has a long service life and maintains stable operation at high speeds, reducing maintenance costs.
| Technical Parameter | Value |
|---|---|
| Product Name | RC-260 Carbon Brush Motor |
| Shaft Type | Round/D Shaft |
| Shaft Length | L±0.5mm |
| Shaft Diameter | 2mm |
| Direction of Rotation | CW/CCW |
| Size | 24.2±0.2mm*26.9mm |
| Torque | 1.43mNm/Custom |
| Current | 2A/Custom |
| Speed | 6000RPM/1200RPM/Or As You Request |
| Model | Voltage(V) | No Load | Rated Load | Stall | ||||||
| Range | Rated | Speed | Current | Torque | Speed | Current | Output | Torque | Current | |
| R/min | A | m.Nm | R/min | A | W | g.cm | A | |||
| RC-260RA-18130 | 4.5-6V | 4.5V | 9800 | 0.14 | 1.48 | 7750 | 0.53 | 1.2 | 72 | 2.0 |
| RC-260RA-2670 | 3-4.5V | 4.5V | 18500 | 0.30 | 2.14 | 15290 | 1.43 | 3.41 | 125 | 6.8 |
| RC-260SA-2670 | 3-4.5V | 4.5V | 13700 | 0.24 | 2.66 | 11520 | 1.27 | 3.2 | 170 | 6.7 |
| RC-260SA-2295 | 3-6V | 4.5V | 10200 | 0.20 | 2.43 | 8300 | 0.87 | 2.11 | 133 | 3.8 |
Customized product parameter are available upon your request Note:1mNm= 1Ncm = 10.2gcm | ||||||||||
Q: Why can't I find the same micro motor model name in your website?
A: The model name of the brushed motor DC product is custom according to different parameter,so if you want to get the same motor you can send your parameter to us,then we can provide the suitable motor for you.
Q: Please quota the price for RC-260SA motor ?
A: Price is base on different material and structure,so you need clarify specific motor requirements, including size, power, speed, voltage, and application scenarios,and annual need.So we can quota the price for you as soon as possible.
.
|
