Square Round Circle Hastelloy C276 UNS N10276 Alloy Thickness 1.0 - 25.0mm For Chemical

• Thickness: 1.0mm ,1.2mm,1.5mm,2.0mm,2.5mm,3.0mm
• Standard Size: 1219*2438mm(4ft*8ft)

Hot Rolled Hastelloy C276 Plate

• Thickness: 4.0mm,5.0mm,6.0mm,8.0mm,10.0mm,12.0mm,14.0mm,16.0mm,20.0mm,25.0mm
• Standard Size: 1500*6000mm, custom laser cutting any size as request

Forged Hastelloy C276 Plate

• Thickness: >25.0mm custom as request
• Size: any size as request

The carefully balanced chemical makeup of Hastelloy C276 contributes to its superior properties. Its primary elements and their typical content ranges are:

• Nickel (Ni): 57% (remainder)
• Molybdenum (Mo): 15-17%
• Chromium (Cr): 14.5-16.5%
• Iron (Fe): 4-7%
• Tungsten (W): 3-4.5%
• Cobalt (Co): 2.5% max
• Manganese (Mn): 1% max
• Vanadium (V): 0.35% max
• Silicon (Si): 0.08% max
• Phosphorus (P): 0.04% max
• Carbon (C): 0.01% max
• Sulfur (S): 0.03% max

Small MOQ Quantity at least 2KG

Availability Options Forms and Formats

Hastelloy C-276 is available in multiple forms to suit diverse industrial needs:

• Bar: Up to 12 inches in diameter.
• Sheet: Thickness ranges from 0.025 to 0.120 inches.
• Plate: Up to 3 inches thick.
• Pipe & Tube: Offered in seamless and welded formats, up to 6 inches nominal bore (NB), with larger sizes available in welded construction.
• Fittings: Includes butt-weld and forged fittings such as elbows, tees, and stub-ends.
• Welding Wire: Supplied in various diameters, classified as ERNiCrMo-4.
• Other Forms: Includes wire spool, wire cuts, loose coil, nipples, couplings, flanges, fasteners, forgings, and machined parts.
