Hot Rolled Steel Plate P355GH / Q345R / 1.0473 Thickness 5.0 - 100mm

Categories	Steel Plate
Brand Name:	BAOSTEEL BENSTEEL HBIS XINGCHENG
Model Number:	Q345R / P355GH
Certification:	ISO 9001
Place of Origin:	China
MOQ:	10 kgs
Price:	540 - 890 USD/Ton
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	20Ton per week
Delivery Time:	5 - 12 days based on the quantity
Packaging Details:	standard packing for export
Products:	Q345R Steel Plate
Thickness:	3.0 - 200.0mm
Width:	1000-2200mm
Length:	2000-12000mm
Standard:	ASTM EN GB
Other Material:	Carbon Steel, Alloy Steel, Stainless Steel
Brand:	BAOSTEEL XINYU XINGCHENG HBIS
Service:	Cutting

Contact Now

Add to Cart

Company Info.

JIANGSU MITTEL STEEL INDUSTRIAL LIMITED

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

Hot Rolled Steel Plate P355GH / Q345R / 1.0473 Thickness 5.0 - 100mm

P355GH Hot Rolled Steel Plate / Pressure Vessel Plate 1500*6000mm 2000*8000mm

Product Name	Q345R / P355GH Steel Plate
Thickness	3mm~300mm,2mm-100mm is common thickness,also can customize
Width	1000~3000mm,common width is 1250mm,1500mm,2000mm,2200mm
Length	1000~12000mm,can as your request cut
Surface	Clean,finished, blasting and painting or as your request
Delivery	Hot Rolled, Controlled Rolling,Normalizing,Annealing, Tempering,Quanching, Q+T
Packing	Steel Strapping,fixing in the Container,can customize
Thickness tolerance	±0.3mm
Application	It is mainly used to make structural parts such as car girder, beam, transmission shaft and car chassis parts, which can reduce the weight of the parts.

Difference in element content

P355GH steel composition(%)

C	Si	Mn	P max	S max	Al-tal	N
0.10-0.22	≤0.40	1.10-1.70	0.0250	0.0150	≤0.020	≤0.012d
Cr	Cub	Mo	Nb	Ni	Ti	V
≤0.30	≤0.30	≤0.08	≤0.020	≤0.30	0.03	≤0.02

P355NH steel composition(%)

C max.	Si max.	Mn max.	P max.	S max.	Al(total)	N max.	Cr max.
0.18	0.50	1.10 -1.70	0.0250	0.0150	0.020	0.012	0.31
Cu max.	Mo max.	Nb max.	Ni max.	Ti max.	V max.	Nb+Ti+ V
0.30	0.08	0.05	0.50	0.03	0.10	0.12

Small difference in category

P355GH steel is a non-alloy steel with specified elevated temperature properties. It is designed in EN 10028-2: 2009 flat products made of steels for pressure purposes standard. P355GH steel is used worldwide by fabricators of welded pressure vessels, industrial boilers and heat exchangers and is engineered to work well in elevated temperature service.

P355NH steel is normalized weldable fine grain steel flats under EN 10028-3: 2009 standard. P355NH steel plate is widely used in petroleum, chemical, power station, boiler and other industries to make reactors, heat exchangers, separators, SPHErical tanks, oil and gas tanks, liquefied gas tanks, nuclear reactor pressure shells, boiler drums, liquefied petroleum gas cylinders, Equipment and components such as high-pressure water pipes of hydropower stations and turbine volutes.
