109MM Full Stroke W01-M58-6166 Firestone Air Spring Assembly 1/4BSP Port Size

Categories Firestone Air Spring
Brand Name: AIRSUSTECH
Model Number: 1B1209
Certification: ISO/TS16949:2009
Place of Origin: Guangzhou,China
MOQ: 1
Price: Negotiable
Payment Terms: T/T, Western Union, Paypal or Others
Supply Ability: 1000PCS/Week
Delivery Time: 5-8 Working Days
Packaging Details: Strong Carton Box or as Customers Requirement
Brand: AIRSUSTECH
Product Number: 1B1209
Dunlop: 8''x1 S08100
Weforma: WBE 300-E2
Pneumatic Connection: 1/4 BSP
Sample: Available
Structure: Single Convoluted
Operation: Gas-Filled
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

109MM Full Stroke W01-M58-6166 Firestone Air Spring Assembly 1/4BSP Port Size

109MM Full Stroke W01-M58-6166 Firestone Air Spring Assembly 1/4BSP Port Size


Product Specifications


  • Cover Plate

Top Cover Plate Diameter 135 mm
Screw Center Distance of Top Cover Plate 70 mm
Bottom Cover Plate Diameter 135 mm
Screw Center Distance of Bottom Cover Plate 70 mm

  • Nut/Blind Nuts

Top Cover Plate Screw(Nut) Tooth 2×M8×1.25
Bottom Cover Plate Screw(Nut) Tooth 2×M8×1.25

  • Gas Hole/Air Inlet/Air Fitting

Air Connection G1/4

  • Rubber Bellow

Rubber Bellow Max. Diameter 215 mm
Compressed Height 50 mm
Max. Expanded Height 115 mm


Other OEM Numbers


Firestone Air Spring: W01-M58-6166

Firestone Air Spring: W01 M58 6166

Firestone Air Spring: W01M586166

Weforma Air Spring: WBE 300-E2

Weforma Air Spring: WBE 300E2

Weforma Air Spring: WBE 300 E2

Dunlop(FR) Air Spring: 8''x1 S08100

Dunlop(FR) Air Spring: 8'x1 S08100

Dunlop(FR) Air Spring: 8x1 S08100
Bosch Air Spring: 822419008

Firestone Style 116
Blind nuts, 1/4 BSP

W01-M58-6166, W01 M58 6166, W01M586166

WO1-M58-6166, WO1 M58 6166, WO1M586166

Blind nuts, 3/4 BSPW01-M58-6165, W01 M58 6165, W01M586165

WO1-M58-6165, WO1 M58 6165, WO1M586165

Countersunk steel bead rings, 40 mm bolts, nuts & washers

W01-358-7568, W01 358 7568, W013587568

WO1-358-7568, WO1 358 7568, WO13587568

Rubber bellows onlyW01-358-0133, W01 358 0133, W013580133

WO1-358-0133, WO1 358 0133, WO13580133


AIRSUSTECH Air Springs Features


1. Rich product variety
2. Accept OEM orders
3. Affordable, safe and efficient logistics services
4. Flexible payment methods
5. Guaranteed warranty

Single Convoluted Rubber Bellows
1B12-305FS 40-6 CISP2906
1B14-350FS 50-5 CISP2334
1B14-352FS 70-7 CISP2913
1B14-364FS 100-10 CISP1536
1B15-376FS 120-10 CISP1537
1B15-378FS 120-12 CISP2523
1B12-313FS 200-10 CISP1540
1B14-351FS 310-12 CISP1543
1B14-362FS 330-11 CI
1B15-377FS 330-14 CI
1B15-375FS 530-11 CI
FS 530-14 CI
FS 960-12 CI
FS 1330-11 CI

1B1209 Real Pictures




Company Profile


Guangzhou Guomate Air Spring Co., Ltd. is located in Guangzhou, China's first open port, just a fifteen-minute drive from Guangzhou Baiyun International Airport. The company boasts a modern building with an area of ​​approximately 20,000 square meters and state-of-the-art production facilities for rubber air springs. It is currently the largest air spring production base in China. The company's products are primarily used in commercial vehicles, rail vehicles, and industrial machinery and equipment. The main products are: rubber air springs, bus airbags, truck airbags, air springs for the paper machine industry, airbags for large washing machines, and rubber air springs for automobiles. We currently offer hundreds of models and designs and can also design and produce according to customer requirements or existing product specifications. New and existing customers are welcome to contact us for a consultation. Our company utilizes state-of-the-art domestic air spring processing facilities and integrates foreign air spring production technologies. Thanks to our unique production process, we produce according to international standards and thus create world-class products.
