| Categories | Stainless Steel Pipe |
|---|---|
| Brand Name: | DELTA |
| Model Number: | 201 304 316L 321 310S 314 347 2205 2507 904L.etc |
| Certification: | ISO |
| Place of Origin: | China |
| MOQ: | 500 kgs |
| Price: | 2400 - 3500 USD/Ton |
| Payment Terms: | T/T, Western Union, L/C |
| Supply Ability: | 10 Ton per week |
| Delivery Time: | 5 - 12 days based on the quantity |
| Packaging Details: | standard packing for export |
| Products: | BA Stainless Steel Pipe |
| Grade: | 304 316L 321 2205 310S 904L.etc |
| Standard: | ASTM GB EN |
| Length: | 6m or as request |
| Diameter: | 6 - 219mm or as clients request |
| Wall thickness: | 0.4 - 8.0mm |
| Type: | seamless pipe |
| Service: | cutting |
| Other Shape: | square, rectangle |
| Company Info. |
| JIANGSU MITTEL STEEL INDUSTRIAL LIMITED |
| Verified Supplier |
| View Contact Details |
| Product List |
Cold Drawn Hot Rolled 310S Stainless Steel Pipe Tube DN5 - DN200
SCH40S SCH80S SCH160S
Products Specification
| Standard | ASTM A213, ASTM A269, ASME SA213, ASME SA269 |
| Pipe Type | Bright Annealed Stainless Steel Tubing |
| Grades | 304, 304L, 316, 316L, 321, 310S, 2205, 2507 |
| Dimensions | Outer Diameter (OD): 1.00 mm to 76.2 mm |
| Wall Thickness | 0.2 mm to 6.0 mm |
| Length | Up to 12 meters (custom lengths available upon request) |
| Manufacturing Process | Cold Drawn, Bright Annealed, Seamless |
| Material Surface Finish | Bright Annealed (BA), Mirror Polished, No. 4 Finish |
| End Type | Plain End (PE), Beveled End (BE), Threaded End (TE) |
| Certifications | ISO 9001, EN 10204 3.1 / 3.2, PED, ASME |
High temperature resistant stainless steel pipe, also known as 310S (0Cr25Ni20) stainless steel, is an austenitic chromium-nickel stainless steel with good oxidation resistance and corrosion resistance. Because of the higher percentage of chromium and nickel, it has much better creep strength. It can continue to operate at high temperatures and has good high temperature resistance.
Cold drawn seamless pipe specifications: outer diameter
6mm---940mm; wall thickness 0.8mm---60mm. Plasma welding and argon
arc welded pipe specifications: outer diameter 12mm---2540mm; wall
thickness 0.5mm---30mm. The theoretical weight calculation formula
of 310S stainless steel round tube: (outer diameter - wall
thickness) × wall thickness × 0.02491 = KG/M
Chemical composition (%) of high temperature resistant 310S
stainless steel pipe: Ni Nickel: 19.00-22.00 Cr Chromium:
24.00-26.00 Si Silicon ＜= 1.50 Mn Manganese ＜= 2.00 C Carbon ＜=
0.08 S Sulfur ＜= 0.030 P Phosphorus ＜= 0.035. Density: 8.0 g/cm3,
mechanical properties after solution treatment: yield strength ≥
205, tensile strength ≥ 520, elongation ≥ 40, hardness test: HBS ≤
187, HRB ≤ 90, HV ≤ 200.
| Element | SS 310 | SS 310S |
| C | 0.015 max | 0.08 max |
| Mn | 2.0 max | 2.0 max |
| Si | 0.15 max | 1.00 max |
| P | 0.020 max | 0.045 max |
| S | 0.015 max | 0.030 max |
| Cr | 24.00 - 26.00 | 24.00 - 26.00 |
| Mo | 0.10 max | 0.75 max |
| Ni | 19.00 - 21.00 | 19.00 - 21.00 |
| Fe | 54.7 min | 53.095 min |
| Element | SS 310/310S |
| Density | 7.9 g/cm3 |
| Melting Point | 1402 °C (2555 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 40 % |
We can also provide the following types and services of plate and
round steel:
Stock size sheets and planks
Stock length round bars
Plate and boards cut to size
Round steel cut to length
Cold forming of plates, plates and round bars
Other additional processing requirements (according to customer
needs)
Our services are designed to meet the specific needs of our
clients, ensuring that the materials supplied meet project
requirements and are of high quality standard. We are committed to
providing efficient, reliable service and ensuring timely delivery.
If you have any needs about stock products or customized products,
please feel free to contact us and we will serve you
wholeheartedly.
|
