| Categories | Long Stroke Pneumatic Gripper |
|---|---|
| Brand Name: | Hyclamavin |
| Model Number: | TPL |
| Certification: | ISO9001 |
| Place of Origin: | China |
| MOQ: | 1 pcs |
| Price: | USD500-1000.00/PC |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 5000 pcs per month |
| Delivery Time: | 4-6 weeks |
| Packaging Details: | Carton Case |
| Operating Temperature: | 0-60°C |
| Operating Pressure: | 0.5-0.7MPa |
| Application: | Assembly, Pick and Place, Packaging |
| Stroke Length: | Long |
| Mounting Type: | Through-hole |
| Actuation: | Pneumatic |
| Jaw Opening Range: | 0-50mm |
| Sensor Type: | Inductive |
| Material: | Aluminum |
| Gripping Force: | High |
| Max. Speed: | 500mm/s |
| Weight: | 0.5kg |
| Jaw Type: | Parallel |
| Max. Payload: | 5kg |
| Company Info. |
| Shanghai Grand Intelligent Machinery Co., Ltd., |
| Verified Supplier |
| View Contact Details |
| Product List |
2-Jaw Pneumatic Parallel Long Stroke Gripper TPL
TPL Grippers with Extended Stroke & Compact Four-Piston Design for Superior Grip and Efficiency
Product Information
Outstanding Performance
1. The TPL grippers are equipped with a long stroke and a four-piston system.
● Longer stroke to accommodate specialized working conditions
● Distinctive four-piston design, reduced volume, and increased gripping force
Model and Technical Parameters
| Model | Stroke per jaw [mm] | Closing/ opening force[N] | Weight [kg] | Recommended workpiece weight[kg] | Closing/ opening time[s] | Repeat accuracy [mm] | Protection class IP |
| TPL-40A | 40 | 1790/1050 | 4.5 | 8.95 | 0.40/0.40 | 0.02 | 40 |
| TPL-70A | 70 | 4450/2940 | 9.1 | 22.25 | 0.70/0.70 | 0.02 | 40 |
