| Categories | DAC Cable |
|---|---|
| Brand Name: | Optowix |
| Model Number: | MF1H-DACXX |
| Certification: | CE |
| Place of Origin: | China |
| MOQ: | 10pcs |
| Payment Terms: | T/T |
| Supply Ability: | 10Kpcs |
| Delivery Time: | 5~8 working days |
| Packaging Details: | ESD plastic case |
| Product Name: | 10G SFP+ Passive Copper Cable Assembly Module |
| Optowix PN: | MF1H-DACXX |
| SpeedRate: | 10G |
| Distrance: | 3m~10m |
| Company Info. |
| Wuhan Optowix Co.,ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
10G SFP+ Passive Copper Cable Assembly Module Optical Transceiver Module
Features
· Up to 10 Gb/s bi-directional data links
· Compliant with 10GFC
· Compliant with SFF-8431
· AC coupled inputs and outputs
· 100 Ohm differential impedance
· Enhanced EMI design
· Single power supply 3.3V
· Operating temperature range: 0◦C to 70◦C
Applications
· 10G Ethernet
· 10G Fiber Channel
· Serial Data Transmission
Standards
· SFF-8431
· IEEE 802.3ae
Ordering information
| Part No. | Description | Gauge | Length |
| MF1H-DACxx-30 | SFP+ Passive Direct Attach Copper Black Cable Assembly,without MCU, xx≤3 | 30AWG | ≤3m |
| MF1H-DACxx-28 | SFP+ Passive Direct Attach Copper Black Cable Assembly,without MCU,xx<5 | 28AWG | <5m |
| MF1H-DACxx-24 | SFP+ Passive Direct Attach Copper Black Cable Assembly,without MCU,xx≤10 | 24AWG | ≤10m |
Description
· Optowix’s 10G passive cable uses shielded high-speed differential cables,compliant with 10 Gigabit Ethernet standards and SFP Multi-Source Agreement (MSA) standards, supports 10G transmission rates, and is backward compatible with 1G rates.SFP 10G passive cable is the preferred solution for short-distance applications. It is widely used for data transmission between data centers and cabinets or adjacent cabinets. Its biggest feature is low cost, ultra-low power consumption (less than 0.1 watt) and high reliability.
Absolute Maximum Ratings
| Parameter | Symbol | Min. | Typ | Max. | Unit | Remarks |
| Data Rate | DR | 10.3125 | 1 | |||
| Bit Error Rate | BER | 10-12 | ||||
| Operating Temperature | Tc | 0 | - | 70 | °C | 2 |
| Storage Temperature | TSTO | -40 | - | 85 | °C | 3 |
| Input Voltage | Vcc | 3.14 | 3.3 | 3.46 | V | 4 |
|
