ONN-M4C Tri Color LED Machine Warning Light Foldable Base CNC Equipment Indicator Light

ONN-M4C Tri-Color LED Machine Warning Light Foldable Base CNC Equipment Indicator

Product Overview

Single-layer Φ60 foldable signal tower light with silver ABS body & PC lens, IP40 dustproof. Equipped low-decay 2835 SMD LEDs, over 90dB loud buzzer, 60–70 flashes per minute. Supports DC24V / AC220V dual power, two wiring modes (universal PNP/NPN & contact type). Foldable base allows 90° angle adjustment, through-hole nut mounting for equipment panels. Multi light modes for machine running/warning/fault indication, CE certified, 18-month warranty.

Quick Detail

• Housing: Silver ABS base + transparent PC lens, Φ60 diameter, IP40 dustproof
• Light source: High-brightness 2835 LED, 360° all-round viewing
• Voltage: DC24V / AC220V, current 60~190mA, total power 1.4~4.5W
• Buzzer: >90dB, flash frequency 60–70 times/min
• Functions: Steady / Red flash / Full flash, buzzer optional
• Wiring: T universal PNP/NPN; C contact signal type
• Mount: Through nut installation, foldable 90° adjustable base
• Surface temp: ＜50℃, LED lifespan: 50,000H
• Standard cable: 0.5m
• Environment: Operate -20~45℃, store -40~70℃, humidity 10%–90%

Specifications

Competitive Advantages

• Foldable adjustable base, 90° bending for flexible light direction
• Dual wide voltage compatible with industrial DC24V and mains AC220V
• High-brightness low-light-decay LED with excellent heat dissipation & long service life
• Two universal wiring schemes match all PLC PNP/NPN controllers
• Multiple light modes + loud buzzer clearly distinguish equipment status
• Simple through-hole nut installation for all machine panel thicknesses

Applications

CNC machining centers, SMT lines, automated packaging, injection molding, robotics workcells, conveyors, and industrial warning systems.

Package Info

12pcs per outer carton, single N.W.0.27kg, carton G.W.5.7kg
