Horizontal LSR Injection Molding Machine Silicone Baby Bottle Production Equipment Fully Automatic Silicone Pacifier Production Equipment

Horizontal LSR Injection Molding Machine Silicone Baby Bottle Production Equipment Fully Automatic Silicone Pacifier Production Equipment

LSR injection machine:vertical sliding /vertical rotary /horizontal etc.

Injection unit:

1. Square hydraulic motor:its position accuracy is ≤0.1MM;

2. Non-return valve between the motor and tube;

3. Bidirectional axial :positioning to avoid the wiggle of the screw；its swing accuracy is ≤0.05MM;

4. Barrel :LSR using ;spline design;pneumatic sealant shut-off nozzle;

5. Injection cylinder:one-piece casting ,its diameter is 5~10mm bigger than normal ;

6. Oil circuit: specially design for LSR, its storage position accuracy is ≤0.05MM;

7. Oil pump : aluminum jacketed oil seal that installs easily and locate well;Oil pump with bidirectional buffering,which moves smoothly;

8. Dorsal bracket ring: protect the O-ring;

9. Air cylinder :internal installed pneumatic sealing needle nozzle；electronic measuring ruler(Gefran-Italy)

10. Optional-Rexroth full closed loop servo valve .(real-time monitoring pressure, speed, back pressure and automatic feedback correction.)

Horizontal Liquid Silicone Rubber (LSR) injection molding machine

Direct pressure mould opening and closing system, horizontal injection structure, it can adjust the mould faster, and control the position more precisely. It is more suitable for producing the LSR parts which can be automatically removed from the mould.

The main feature of the horizontal LSR molding machine:

A.Newly-optimized integrated all-in-one design.

B. Meet multiple requirements on the automatic manufacturing technique for LSR products.

C. Shorter the mould closing and opening time, improve the production efficiency.

D. Remote control function.

E. Multisection mould closing and opening and injection, speed adjusting stepless.

Service:

What Makes Silicone Rubber So Desirable?

Silicone rubber is a synthetic elastomer made from silicon, oxygen, hydrogen, and carbon. Known for its exceptional resistance to extreme temperatures, ranging from -60°F to 450°F[KC1], silicone rubber is highly durable and flexible. It also possesses strong resistance to environmental elements like UV light, moisture, and ozone, making it suitable for outdoor and demanding applications.
These properties make silicone rubber the go-to material for industries that require long-lasting, high-performance solutions. Its ability to maintain stability in harsh conditions allows manufacturers to rely on it in critical applications.
Below, we will review the wide range of silicone rubber applications across industries such as automotive, energy, aerospace, and more, demonstrating its integral role in modern technology and infrastructure.
