The cold rolled steel coil (plate) production process is as
follows:
1.Raw material preparation: cold rolled steel coil production
mainly uses hot rolled coil or hot rolled steel plate as raw
materials these raw materials first need to carry out quality
checks to ensure that it meets the production requirements
Pre-treatment: The raw material is heated and cleaned to remove
surface oxides and dirt, making the surface of the billet smoother
and ready for subsequent processing.
2.Cold rolling: the raw material is fed into multi-pass cold
rolling mills for rolling These mills usually consist of 4-6
passes, each with a decreasing diameter of rolls, and the raw
material is rolled to the required thickness and width by pressing
and stretching In the process of cold rolling, surface treatments
such as embossing, trimming, and polishing are also carried out on
the steel plate.
3.Pickling: After rolling, the steel plate is pickled to remove the
oxide skin and rust scale on the surface and to improve the
flatness and finish of the steel plate surface.
4.Oiling: After pickling, the steel plate is oiled to prevent
surface oxidation and corrosion, and to reduce friction and
scratches during stacking, transport and processing.
5.Cutting: The steel plate is cut into the required length and
width to meet the needs of different industries.
6.Packaging: The cut steel plates are packaged and labelled with
relevant information, such as plate specifications, batch number
and production date.
| Deliverable Grade | ||||||||
| Standard | Q/BQB 408 | JIS G3141 | JFS A2001 | EN 10130 | DIN 1623 | ASTM A1008 | GB/T 5213 | ISO 3574 |
| Grade | BLC | SPCC | JSC270C | DC01 | St12 | CS | CR1 | |
| BLD | SPCD | JSC270D | DC03 | RRSt13 | DS | CR2 | ||
| BUSD | SPCE | JSC270E | DC04 | St14 | DDS | SC1 | CR3 | |
| BUFD | SPCF | JSC270F | DC05 | EDDS | SC2 | CR4 | ||
| BSUFD | JSC260G | DC06 | SC3 | CR5 | ||||
| Standard | Grade | Chemical Composition of Cold Rolled Mild Steel(%) | Mechanical properties of cold rolled steel | ||||||
| C | Si | Mn | P | S | Yielding Strength (MPa) | Tensile Strength (MPa) | Elongation (%) | ||
| JIS G3141 | SPCC | 0.15 max | - | 0.60 max | 0.10 max | 0.05 max | |||
| SPCD | 0.12 max | - | 0.50 max | 0.04 max | 0.04 max | ≤ 240 | ≥ 270 | ≥ 41 | |
| SPCE | 0.10 max | - | 0.45 max | 0.03 max | 0.03 max | ≤ 220 | ≥ 270 | ≥ 43 | |
| SPCF | 0.08 max | - | 0.45 max | 0.03 max | 0.03 max | ≤ 210 | ≥ 270 | ≥ 45 | |
| JIS G3141 Surface quality classification: B-finish; D-mirror finish Heat treatment or state: A - annealed; S - tempered , 8 -1/8 hard, 4-1/4 hard, 2-1/2 hard, 1-hard | |||||||||
| EN 10130 | DC01 | 0.12 max | - | 0.60 max | 0.045 max | 0.045 max | 140-280 | 270-410 | ≥ 28 |
| DC03 | 0.10 max | - | 0.45 max | 0.035 max | 0.035 max | 140-240 | 270-370 | ≥ 34 | |
| DC04 | 0.08 max | - | 0.40 max | 0.030 max | 0.030 max | 140-210 | 270-350 | ≥ 38 | |
| DC05 | 0.06 max | - | 0.35 max | 0.025 max | 0.025 max | 140-180 | 270-330 | ≥ 40 | |
| DC06 | 0.02 max | - | 0.25 max | 0.020 max | 0.020 max | 120-170 | 270-330 | ≥ 41 | |
| Surface type: A, B; Surface specification: b=special smooth,
g=smooth, m=non-glossy, r=rude Example of plate naming: EN 10130+A1-DC03-B-g where B is the surface type and g indicates that the surface specification is smooth | |||||||||


|
