| Categories | Laser Cutting Machine |
|---|---|
| Place of Origin: | Jiangsu, China |
| Brand Name: | hoston |
| MOQ: | 1 |
| Price: | $15,000-20,000 |
| Laser type: | Fiber Laser |
| Cutting area: | 2500mm*6000mm |
| Cutting speed: | 120m/min |
| Cutting thickness: | 20mm |
| Cooling mode: | Air Cooling |
| Machine weight: | 12000 KG |
| Machine dimension: | 8500*6200*2300mm |
| Laser power: | 1500-15000W |
| X/Y accuracy: | ±0.08mm |
| Max acceleration: | 1.0G |
| Operating voltage: | 380V/50Hz |
| Running temperature: | 0°-40° |
| Transmission type: | Precise rack and pinion |
| Power consumption: | 10 kW |
| Running humidity: | <90% |
Model | 1530 | 1540 | 2040 | 2060 |
Working Area (mm) | 1500×3000 | 1500×4000 | 2000×4000 | 2000×6000 |
Machine Dimension (mm) | 12006×6000×2400 | 13000×6000×2400 | 13000×6400×2400 | 15500×6400×2400 |
Pipe Dimension (mm) | 20~219 | 20~219 | 20~219 | 20~219 |
Square tube length (mm) | 20~150 | 20~150 | 20~150 | 20~150 |
The length of the pipe (mm) | 6000 | 6000 | 6000 | 6000 |
Max. Cutting Speed (m/min) | 120 | 120 | 120 | 120 |
Max. Acceleration (G) | 0.8 | 0.8 | 0.8 | 0.8 |
X/Y Positioning Accuracy (mm) | ±0.08 | ±0.08 | ±0.08 | ±0.08 |
X/Y Repeated Positioning Accuracy (mm) | ±0.05 | ±0.05 | ±0.05 | ±0.05 |
Operating Voltage (V/Hz) | 380/50 | 380/50 | 380/50 | 380/50 |
Laser power (W) | 1500-4000 | 1500-4000 | 1500-4000 | 1500-4000 |
Power consumption (kW) | 10 | 10 | 10 | 10 |
Machine Running Temperature (℃) | 0-40 | 0-40 | 0-40 | 0-40 |
Machine Running Humidity | <90% | <90% | <90% | <90% |
Transmission | Precise rack and pinion | Precise rack and pinion | Precise rack and pinion | Precise rack and pinion |
|
