Concrete Pump Wear Plate DN200/230/260 Tungsten Carbide 15-20mm

Categories	Concrete Pump Truck Parts
Place of Origin:	China
MOQ:	1
Price:	$164-$198
Material:	Tungsten carbide, Alloy
Type/Size:	DN200/230/260
Dual carbide thickness:	15+5mm
Single carbide thickness:	15mm
Full carbide thickness:	20mm
Wear Plate weight (200):	20.87 kgs
Wear Plate weight (230):	22.5 kgs
Wear Plate weight (260):	24.25 kgs
Cutting Rings weight (200):	7.92 kgs
Cutting Rings weight (230):	8.3 kgs
Cutting Rings weight (260):	8.1 kgs
Carbide hardness:	HRA ≥85
Electrode hardness:	HRC ≥65
Cutting Ring types:	Single Alloy, Twin Alloy, Full Alloy
MOQ:	1 piece

Contact Now

Add to Cart

Company Info.

Hunan Jiancheng Technology Co., Ltd

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

Concrete Pump Wear Plate DN200/230/260 Tungsten Carbide 15-20mm

Product Description

Concrete pump tungsten carbide spectacle wear plate

Dual carbide 15+5mm

Single carbide 15mm

full carbide 20mm for choices

Desp	Item No.（Size）	Weight(kgs)	Material
Wear Plate	590653（200）	20.87	Carbide HRA：≥85 Electrode HRC：≥65
Wear Plate	500011（230）	22.5	Carbide HRA：≥85 Electrode HRC：≥65
Wear Plate	500007（260）	24.25	Carbide HRA：≥85 Electrode HRC：≥65
Cutting Rings	590654/590660(200)	7.92	Carbide HRA：≥85 Electrode HRC：≥65
Cutting Rings	500012/590129(230)	8.3	Carbide HRA：≥85 Electrode HRC：≥65
Cutting Rings	500008/590165(260)	8.1	Carbide HRA：≥85 Electrode HRC：≥65

How to increase service life of concrete pump spectacle wear plate and cutting ring ?

When the pump is in operation, the basic causes of wear resulted due to the following 3 actions on cutting rings and spectacle plate.

1. Friction created while rubbing away on wear parts.

2. Impact stress due to intentional back pressure created for better sealing.

3. By the concrete due to the flow. To reduce the maintenance cost, we suggest to use carbide type and change wear ring position after working for a period of time.

Cutting Rings

200/230/260

Cutting Ring

Single Alloy, Twin Alloy, Full Alloy

Packing & Delivery

Company Profile

Hunan Jiancheng Technology Co., Ltd. is focusing on the R&D, manufacturing and marketing of Mechanical Components and Spare Parts for Concrete Machinery.

You can get ONE-STOP purchasing services at Jiancheng.
