NUP2105LT1G AEC-Q101 CAN Protector with ±30kV ESD IEC61000-4-2 Low 5pF 2-Line Bidirectional Protection Flow-Through Design and SOD-123 Package

NUP2105LT1G AEC-Q101 CAN Protector with andplusmn;30kV ESD IEC61000-4-2 Low 5pF 2-Line Bidirectional Protection Flow-Through Design andamp; SOD-123 Package

andnbsp;

Features

andbull; 350 W Peak Power Dissipation per Line (8/20 sec Waveform)

andbull; Low Reverse Leakage Current (andlt; 100 nA)

andbull; Low Capacitance Highandminus;Speed CAN Data Rates

andbull; IEC Compatibility:

andnbsp; andminus; IEC 61000andminus;4andminus;2 (ESD): Level 4, 30 kV

andnbsp; andminus; IEC 61000andminus;4andminus;4 (EFT): 40 A andndash; 5/50 ns

andnbsp; andminus; IEC 61000andminus;4andminus;5 (Lighting) 8.0 A (8/20 s)

andbull; ISO 7637andminus;2 Pulse 2a: Repetitive Load Switch Disconnect, 9.5 A

andbull; ISO 7637andminus;3 Pulse 3a,b: Repetitive Load Switching Fast Transients, 50 A

andbull; Flammability Rating UL 94 Vandminus;0

andbull; SZ Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AECandminus;Q101 Qualified and PPAP Capable

andbull; These Devices are Pbandminus;Free, Halogen Free/BFR Free and are RoHS Compliant

andnbsp;

Applications

andbull; Industrial Control Networks

andnbsp; anddiams; Smart Distribution Systems (SDSandreg;)

andnbsp; anddiams; DeviceNetandtrade;

andbull; Automotive Networks

andnbsp; anddiams; Low and Highandminus;Speed CAN

andnbsp; anddiams; Fault Tolerant CAN

andnbsp;

Description

The SZ/NUP2105L has been designed to protect the CAN transceiver in highandminus;speed and fault tolerant networks from ESD and other harmful transient voltage events. This device provides bidirectional protection for each data line with a single compact SOTandminus;23 package, giving the system designer a low cost option for improving system reliability and meeting stringent EMI requirements.

andnbsp;

INFORMATION
