1/2/4/8-Ch SD-SDI/ASI Unidirectional Fiber Optic Transmitter/Receiver

1/2/4/8-Ch SD-SDI/ASI Unidirectional Fiber Optic Transmitter/Receiver

► 8x10/100/1000M/2.5GBase-TX + 2x1.25G/2.5G/10G SFP+ Base-FX

► 10/100/1000M/2.5Gbps RJ45 Port Supports Full/Half-duplex, Auto-negotiation, Auto MDI/MDIX

► Supports IEEE 802.3at PoE+ (30W per port)

► Supports 802.3x Flow Control

► IEEE 802.3az Energy Efficient Ethernet (EEE)

► Redundant Power Inputs

► Supports DIN-Rail mount installation

► -40°C to 80°C (-40°F to 176°F) operating temperature.

Overview

The SD-SDI/ASI provides customer with the most cost-effective solution for transmission of 1-8 channel unidirectional SDI/ASI digital video signal, with 1+1 remote input redundancy and 1 local input redundancy optional. It is an easy installation and adjustment free device while providing high quality, real-time video. It is widely used in the field of CCTV, video surveillance, and etc.

Technical Indexes

Serial TV BNC Input
TV signal standard	SMPTE 259M, 297M, 305M, 310M, M2S, DVB-ASI, DVB-SSI and other Telecom/Datacom rate
Input channel	1-8
Reflection loss	>15DB
Equilibrium	0-250m
Connector	75Ω BNC
Serial TV BNC Output (EO/OE)
Output channels	1-8
Signal level	800mV nominal
Rise/fall time	200Ps nominal
Overshoot	<10% amplitude
Reflection loss	> 15dB
Jitter	< 0.3UI
Connector	75Ω BNC
Optic Output
Channel	1
Type	Single-mode/fiber (multimode optional)
Wavelength	CWDM wavelenth
Reflection loss	> 15dB
Jitter	< 0.3UI
Connector	FC/PC(ST/PC optional)
Power and environmental indicator
Operating temperature	-45℃～＋50℃
Pressure	1A@12VDC
Power	12W
EMI/RFI	FCC Part 15 Class A, EU EMC standard
Average time trouble-free	>100000 hours
Regulatory Approvals
ISO9001
FCC part 15, Class A
EN55022:2006+A1: 2007 Class A
Surge Protection:

Application

Ordering Information

Model	Description
LNK-2010-T	1-Ch SD-SDI/ASI with embedded audio input, single mode(multimode optional), single fiber, FC/PC fiber connector, BNC video interface, 0-120km, stand-alone or 1U rack mount
LNK-2010-R	1-Ch SD-SDI/ASI with embedded audio output, single mode(multimode optional), single fiber, FC/PC fiber connector, BNC video interface, 0-120km, stand-alone or 1U rack mount
LNK-2020-T	2-Ch SD-SDI/ASI with embedded audio input, single mode(multimode optional), single fiber, FC/PC fiber connector, BNC video interface, 0-120km, stand-alone or 1U rack mount
LNK-2020-R	2-Ch SD-SDI/ASI with embedded audio output, single mode(multimode optional), single fiber, FC/PC fiber connector, BNC video interface, 0-120km, stand-alone or 1U rack mount
LNK-2040-T	4-Ch SD-SDI/ASI with embedded audio input, single mode(multimode optional), single fiber, FC/PC fiber connector, BNC video interface, 0-120km, stand-alone or 1U rack mount
LNK-2040-R	4-Ch SD-SDI/ASI with embedded audio output, single mode(multimode optional), single fiber, FC/PC fiber connector, BNC video interface, 0-120km, stand-alone or 1U rack mount
LNK-2080-T	8-Ch SD-SDI/ASI with embedded audio input, single mode(multimode optional), single fiber, FC/PC fiber connector, BNC video interface, 0-120km, stand-alone or 1U rack mount
LNK-2080-R	8-Ch SD-SDI/ASI with embedded audio output, single mode(multimode optional), single fiber, FC/PC fiber connector, BNC video interface, 0-120km, stand-alone or 1U rack mount

Tags:

Fiber Optic Transmitter Fiber Optic Rreceiver ASI Converter

Product Tags:

SD-SDI fiber optic transmitter

ASI unidirectional video converter

multi-channel fiber optic receiver

1/2/4/8-Ch SD-SDI/ASI Unidirectional Fiber Optic Transmitter/Receiver

Send your message to this supplier


*From:	Your email address is incorrect!
*To:	E-link China Technology Co.,LTD
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Categories	Video Fiber Converter
Brand Name:	E-link
Model Number:	LNK-2000 Series
Certification:	CE, FCC, RoHS
Place of Origin:	China
MOQ:	1pcs
Price:	$29-769
Payment Terms:	L/C,T/T,Western Union,MoneyGram,PayPal
Supply Ability:	100000PCS/Month
Delivery Time:	7-10 working days
Packaging Details:	Standard Export Package
Operating Temperature:	-45℃～＋50℃
Signal level:	800mV nominal
Equilibrium:	0-250m
Connector:	75Ω BNC
Overshoot:	<10% amplitude
Jitter:	< 0.3UI
